4.76 mm Outside Diameter 0.50 mm Wall Thickness SAE J526 Welded Low-Carbon Steel Tubing in SAE 1008 and SAE 1010 Grades
Basic Properties
Place of Origin:
ZheJiang/China
Brand Name:
TORICH
Certification:
ISO9001, ISO14001, TS16949
Model Number:
SAE J 526
Trading Properties
Minimum Order Quantity:
1Ton
Price:
800-1000 USD/Tons
Payment Terms:
L/C,D/A,D/P,T/T,Western Union
Supply Ability:
60000 Ton/Tons per Year
Product Summary
4.76 × 0.50 mm SAE J526 Welded Low-Carbon Steel Coil Tubing This electric-resistance-welded, single-wall, low-carbon steel precision tube is supplied in level-wound or pancake coils. It is manufactured for compact fluid-conductor assemblies requiring controlled bending, beading, brazing and end ...
Product Details
Product:
Single-wall Welded Low-carbon Steel Coil Tubing
Standard:
SAE J526
Grades:
SAE 1008 / UNS G10080 And SAE 1010 / UNS G10100
Outside Diameter:
4.76 Mm
Wall Thickness:
0.50 Mm
Length:
Continuous Coil Length By Order; Straight Lengths Generally 1–12 M, Customizable
Surface Condition:
Plain, Lightly Oiled, Zinc Coated, Copper Coated, Phosphate Coated Or Customer-specified Coating
Heat Treatment:
As-welded And Processed, Stress Relieved Or Annealed According To Forming Requirements
Product Description
4.76 × 0.50 mm SAE J526 Welded Low-Carbon Steel Coil Tubing
This electric-resistance-welded, single-wall, low-carbon steel precision tube is supplied in level-wound or pancake coils. It is manufactured for compact fluid-conductor assemblies requiring controlled bending, beading, brazing and end forming.
Key Dimensions
- Outside diameter: 4.76 mm
- Wall thickness: 0.50 mm
- Calculated inside diameter: 3.76 mm
- Calculated theoretical mass: approximately 52.5 g/m
- Optional proof pressure: 250 kgf/cm², approximately 24.5 MPa
Technical Specifications
| Item | Technical Specification |
|---|---|
| Product | Single-wall welded low-carbon steel coil tubing |
| Manufacturing process | Strip forming followed by electric-resistance welding |
| Standard | SAE J526 |
| Referenced material standard | SAE J403 |
| Primary grades | SAE 1008 / UNS G10080 and SAE 1010 / UNS G10100 |
| Outside diameter | 4.76 mm |
| Wall thickness | 0.50 mm |
| Calculated inside diameter | 3.76 mm |
| Theoretical mass | Approximately 52.5 g/m |
| Supply form | Level-wound coil, pancake coil or straight cut length |
Main Characteristics
Controlled Small-Diameter Geometry: For a nominal outside diameter of 4.76 mm and a 0.50 mm wall, featuring nominal inside diameter of 3.76 mm and theoretical mass of approximately 52.5 g/m.
Formability: SAE J526 finished tubing features tensile strength of 290 MPa minimum, yield strength of 170 MPa minimum, and elongation over 50 mm of 14% minimum.
Welded Construction: Formed from one steel strip and longitudinally welded with external weld reinforcement removed for smooth surface.
Our Advantages
- Dimensional Control: Precise management of the nonstandard 0.50 mm wall thickness
- Weld-Seam Management: Controlled internal bead height and external scarfing for leak-proof performance
- Stable Coil Processing: Consistent winding and traceability throughout production
Chemical Composition
| SAE Grade | UNS Number | C, % | Mn, % | P, % Max. | S, % Max. |
|---|---|---|---|---|---|
| SAE 1006 | G10060 | ≤0.08 | 0.25-0.40 | 0.030 | 0.035 |
| SAE 1008 | G10080 | ≤0.10 | 0.30-0.50 | 0.030 | 0.035 |
| SAE 1010 | G10100 | 0.08-0.13 | 0.30-0.60 | 0.030 | 0.035 |
Application Field
Primarily used in automotive hydraulic brake tube assemblies, processed into double-flared configurations with validated burst pressure, proof pressure, vibration, corrosion, fatigue, fitting pull-off and leakage performance.
Product Images
Frequently Asked Questions
Are you trading company or manufacturer?
We are a manufacturer, but we can also handle trading operations.
How long is your delivery time?
Generally 10-15 days if goods are in stock, or 30-40 days if not in stock, depending on quantity.
Do you provide samples? Is it free or extra?
Yes, we offer samples free of charge, but the customer pays the freight cost.
What is your terms of payment?
Payment ≤ 2000 USD: 100% in advance. Payment ≥ 2000 USD: 30% T/T in advance, balance before shipment.
