ASTM A789 / ASME SA789 Stainless Steel Pipe Ferritic Stainless Steel Tubing For General Service
Product Details
ASME SA789 Stainless Steel Pipe
,Ferritic Stainless Steel Tubing
,6m Stainless Steel Pipe
ASTM A789/ASME SA789 Stainless Steel Pipe Ferritic Stainless Steel Tubing For General Service
Introduction
The ASTM A789/ASME SA789 specification covers seamless and welded ferritic/austenitic stainless steel tubing for general service. This type of stainless steel pipe is widely used in various industries due to its excellent corrosion resistance and high strength.
Material
The ASTM A789/ASME SA789 stainless steel pipe is made from a combination of ferritic and austenitic stainless steels. The most commonly used grades include:
- Grade TP 304: This grade contains 18% chromium and 8% nickel.
- Grade TP 304L: Similar to Grade TP 304, but with a lower carbon content to improve weldability.
- Grade TP 316: Contains 16% chromium, 10% nickel, and 2% molybdenum, offering increased corrosion resistance.
- Grade TP 316L: Similar to Grade TP 316, but with a lower carbon content for improved weldability.
Specification
The ASTM A789/ASME SA789 stainless steel pipe specifications include:
- Size Range: The pipes are available in various sizes, ranging from 1/8" to 30" (10.3mm to 762mm) in outer diameter.
- Wall Thickness: The wall thickness can vary from SCH 5S to SCH XXS.
- Length: Standard pipe lengths are 20 feet (6 meters) or customized according to specific requirements.
Chemical Composition
The chemical composition of ASTM A789/ASME SA789 stainless steel pipes is given in the table below:
| Element | Grade TP 304 | Grade TP 304L | Grade TP 316 | Grade TP 316L |
|---|---|---|---|---|
| Carbon (C) | 0.08% max | 0.030% max | 0.08% max | 0.030% max |
| Manganese (M) | 2% max | 2% max | 2% max | 2% max |
| Phosphorus (P) | 0.045% max | 0.045% max | 0.045% max | 0.045% max |
| Sulfur (S) | 0.030% max | 0.030% max | 0.030% max | 0.030% max |
| Silicon (Si) | 1% max | 1% max | 1% max | 1% max |
| Chromium (Cr) | 18% - 20% | 18% - 20% | 16% - 18% | 16% - 18% |
| Nickel (Ni) | 8% - 10.5% | 8% - 12% | 10% - 14% | 10% - 14% |
| Molybdenum (Mo) | - | - | 2% - 3% | 2% - 3% |
Mechanical Properties
The mechanical properties of ASTM A789/ASME SA789 stainless steel pipes are listed below:
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
|---|---|---|---|
| TP 304 | 515 min | 205 min | 35 min |
| TP 304L | 485 min | 170 min | 35 min |
| TP 316 | 515 min | 205 min | 30 min |
| TP 316L | 485 min | 170 min | 30 min |
Application
The ASTM A789/ASME SA789 stainless steel pipe finds applications in a wide range of industries, including:
- Chemical processing: The excellent corrosion resistance of these pipes makes them suitable for handling various chemicals.
- Petrochemical industry: The pipes are used in the refining and processing of petroleum products.
- Power generation: They are utilized in power plants for conveying fluids and gases at high temperatures and pressures.
- Food and beverage industry: The hygienic properties of stainless steel make it ideal for transporting food and beverages.
- Pharmaceutical industry: Stainless steel pipes are widely used for conveying drugs and other chemicals in pharmaceutical manufacturing.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
