Torich Cold Drawn Shock Absorber Tube For Hyduaulic Power System
Product Details
Torich shock absorber tube
,Cold Drawn shock absorber tube
,shock absorber Cold Drawn tube
Torich Cold Drawn Shock Absorber Tube for Hyduaulic Power System
Referenced Standard:
EN10027-1, Designation system for steels-part1: Steel names
EN10027-2, Designation system for steels-part2: Numerical system
EN10204:2004,Metallic products-Types of inspection documents
EN10266:2003 Steel tubes, fittings and structural hollow sections- symbols and definitions of terms for use in products standard
Chemical composition:
| Steel grade | % by mass | ||||||||
| Steel name | Steel number | C max | Si max | Mn max | P max | S max | Al min | ||
| E215 | 1.0212 | 0.10 | 0.05 | 0.7 | 0.025 | 0.015 | 0.025 | ||
| E235 | 1.0308 | 0.17 | 0.35 | 1.2 | 0.025 | 0.015 | 0.015 | ||
| E355 | 1.0580 | 0.22 | 0.55 | 1.6 | 0.025 | 0.015 | 0.02 | ||
Mechanical Properties:
| Steel grade | Mechanical properties | ||||||||
| Steel name | Steel number | Yield strength ReH min MPa | Tensile strength RM MPa | Elongnation after fracture A min % | |||||
| E215 | 1.0212 | 215 | 290-430 | 30 | |||||
| E235 | 1.0308 | 235 | 340-480 | 25 | |||||
| E355 | 1.0580 | 355 | 490-630 | 22 | |||||
| Product Name | Automobile gas spring shock absorber steel pipes |
| Standard | EN10305, DIN 2393, ASTM A519, etc |
| Material | 1020, 16Mn, etc |
| Usage | Automobile, hydraulic ,shock absorber,etc |
| Technique | Cold drawn |
| OD | 5-420mm |
| WT | 0.5-50mm |
| Length | Max 12000mm |
| Tolarance | ±3% |
| Certification | ISO9001 ISO14001 TS16949 |
| Section Shape | Round |
| Payment | T/T ,L/C,Money Gram, Western Union |
| Delivery | FOB,CIF,CFR,CPT,etc |
| Package | Packed in hexagonal in boxes |
Product Show:
QUALITY CONTROL
1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
A&Q
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample of SCM 440 42CrMo Mechanical Tubing for Reinforcement sleeve for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
-
