ERW Precision Steel Tubes ERW Precision Tubes
Basic Properties
Place of Origin:
Zhejiang,China
Brand Name:
TORICH
Certification:
ISO9001,ISO14001,TS16949
Model Number:
ASTM A513/SAE J525/EN10305/DIN2393
Trading Properties
Minimum Order Quantity:
5 tons
Price:
888 usd per ton
Payment Terms:
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:
50000 tons per year
Product Summary
ERW Precision Steel Tubes ERW Precision Tubes TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience. Our main products are seamless precision steel tubes,ERW precision steel tubes. The material we usually use for producing ERW precision ...
Product Details
Highlight:
SAE1010 Precision Steel Tube
,OD 420mm Precision Steel Tube
,ASTM A513 Seamless Hydraulic Tubing
Product Name:
ERW Precision Steel Tubes ERW Precision Tubes
Keyword:
ERW Precision Steel Tubes
Usage:
For Automotive Shock Absorber,engine Application
Shape:
Round
Technique:
ERW(electric Resistance Welded)
Material:
1010,1020,1045,4130,4140
OD:
5-420mm
WT:
0.5-50mm
Length:
Max12000mm
Package:
Standard Marine Package
Product Description
ERW Precision Steel Tubes ERW Precision Tubes
TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience.
Our main products are seamless precision steel tubes,ERW precision steel tubes. The material we usually use for producing ERW precision steel tubes is Q195,Q235,Q345,ST37,ST44,ST52,ETC.
Applications:
Automotor, hollow stabilizer bar, drive shaft tube, steering tube, shock absorber tube, camshaft pipe, precision machinery equipment etc.
Standard:
ASTM A513 cold rolling welded precision steel tubes
Steel Grade:
SAE1010, SAE1020, SPCC,SPHC,other materials upon agreement with customers.
Production method:
Cold rolling on the weled steel tubes, to reach high accuracy on the OD and WT tolerance
Size range:
O.D.:6-350mm W.T.:1-15mm L:max12000mm
Packing:
In Hexagonal Bundles, with anti corrosion oil protection, with seaworthy packing
Delivery condition:
1. A.W.H.R. "as welded" from hot-rolled steel
2. A.W.C.R. "as welded" from cold-rolled steel
3. S.D.C.R. "sink-drawn", cold-rolled steel
5. M.D. mandrel drawn
6. S.S.I.D. special smooth inside diameter
Please specify the delivery condition when sending the enquiry!
Thermal condition:
1. No final thermal treatment
2. Stress relieved
3. Annealed
4. Normalized
| Steel Grade and Chemical Compositions: | |||||||
| Steel Grade | C | Mn | P | S | Si | Cr | Mo |
| max | max | max | max | min | |||
| 1008 | 0.10 | 0.5 | 0.035 | 0.035 | |||
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.035 | 0.035 | |||
| 1018 | 0.14-0.20 | 0.30-0.60 | 0.035 | 0.035 | |||
| 1020 | 0.17-0.23 | 0.30-0.60 | 0.035 | 0.035 | |||
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.035 | 0.035 | |||
| 1035 | 0.31-0.38 | 0.60-0.90 | 0.035 | 0.035 | |||
| 4130 | 0.28-0.33 | 0.40-0.60 | 0.035 | 0.035 | 0.15-0.35 | 0.80-1.10 | 0.08-0.25 |
| 4140 | 0.38-0.43 | 0.75-1.00 | 0.035 | 0.035 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
FAQ
Q: Are you trading company or manufacturer ?
A: We are professional steel tube manufacture since 1997
Q: What certificates do you have ?
A: IATF16949,ISO9001,SGS
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but you need pay the cost of freight.
