Double Wall PVF Coated Bundy Low Carbon Steel Tube
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO9001 TS16949
Model Number:
ISO9001
Trading Properties
Minimum Order Quantity:
2 tons
Payment Terms:
L/C, T/T
Supply Ability:
50000 TONS PER YEAR
Product Summary
Bundy Tube Bundy Pipe PVF Coated Bundy Tubes Copper brazed double wall steel tube is made of steel strips which is copper plated on both sides.It has widely applied for automobiles,refrigerators and the other hydraulic system industries. Dimension and specification O.D. mm Thickness mm Weight g/m ...
Product Details
Highlight:
PVF Coated Steel Tube
,Bundy Low Carbon Steel Tube
Product Name:
Bundy Tube Bundy Pipe PVF Coated Bundy Tubes
Size:
4.76，6.35
Length:
Straight Or Coil
End:
Plain End Or BE
Material:
Low Carbon Steel
Coating:
PVF
Product Description
Bundy Tube Bundy Pipe PVF Coated Bundy Tubes
Copper brazed double wall steel tube is made of steel strips which is copper plated on both sides.It has widely applied for automobiles,refrigerators and the other hydraulic system industries.
Dimension and specification
| O.D. mm | Thickness mm | Weight g/m | Assurance pressure kg/cm3 |
| 4.76 | 0.7 | 70.28 | 350 |
| 6.00 | 0.7 | 91.76 | 350 |
| 6.35 | 0.7 | 97.75 | 350 |
| 7.00 | 0.7 | 108.75 | 350 |
| 7.14 | 0.7 | 111.17 | 350 |
| 8.00 | 0.7 | 126.31 | 350 |
Tolerance
O.D. and W.T. +/-0.08mm
Chemical Composition
C ≤ 0.12%
Mn ≤ 0.50%
P≤ 0.04%
S≤ 0.045%
Mechanical properties
Tensile strength ≥30kgf/mm2
Yield point ≥18kgf/mm2
Elongation(50mm)≥25%
Hardness(HR30T)≤ 65
Expand test Take 3 samples of 200mm,expand the pipe outside dimension to larger than 25%
Internal cleanliness Particle and oil ＜0.194g/m2
