Carbon And Alloy Steel Automotive Steel Tubes , Round Mechanical Tubing
Basic Properties
Place of Origin:
Zhejiang,China
Brand Name:
TORICH
Certification:
ISO9001 ISO14001 TS16949
Model Number:
ASTM A519 DIN 2391, EN 10305-1, SAE J524, and GB/T 3639
Trading Properties
Minimum Order Quantity:
3 TONS
Price:
negotiable
Payment Terms:
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:
5000 TONS PER MONTH
Product Summary
Carbon and Alloy Steel Mechanical Tubing Automotive Steel Tubes from TORICH Products Information: Size Range: OD: 4.0-350mm WT:0.5-50mm Length: max 12000mm Thickwall Steel Tube is our strength and regular production montly, mainly for machinery and engineering parts for our customers. Steel Grade...
Product Details
Highlight:
low carbon steel pipe
,steel mechanical tubing
Product Name:
Carbon And Alloy Steel Mechanical Tubing Automotive Steel Tubes From TORICH
Keyword:
Automotive Steel Tubes
Application:
For Mechinery, Mechanical Engineer
Shape:
Round
Material:
1008 1010 1020 1045 ST52 ST52.3 E355 ST37 16Mn
Delivery Condition:
HR CW SR A N
OD:
5-420mm
WT:
0.5-50mm
Length:
Max 12000mm
Brand:
TORICH
Product Description
Carbon and Alloy Steel Mechanical Tubing Automotive Steel Tubes from TORICH
Products Information:
Size Range:
OD: 4.0-350mm
WT:0.5-50mm
Length: max 12000mm
Thickwall Steel Tube is our strength and regular production montly, mainly for machinery and engineering parts for our customers.
Steel Grade/Steel Material:
| Steel Grade and Chemical Compositions: | |||||||
| Steel | C | Mn | P | S | Si | Cr | Mo |
| Grade | max | max | max | max | min | ||
| 1008 | 0.10 | 0.30-0.50 | 0.040 | 0.050 | |||
| 1010 | 0.08-0.13 | 0.30-0.60 | 0.040 | 0.050 | |||
| 1018 | 0.15-0.20 | 0.60-0.90 | 0.040 | 0.050 | |||
| 1020 | 0.18-0.23 | 0.30-0.60 | 0.040 | 0.050 | |||
| 1026 | 0.22-0.28 | 0.60-0.90 | 0.040 | 0.050 | |||
| 1035 | 0.32-0.38 | 0.60-0.90 | 0.040 | 0.050 | |||
| 1045 | 0.43-0.50 | 0.60-0.90 | 0.040 | 0.050 | |||
| 4130 | 0.28-0.33 | 0.40-0.60 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
| 4140 | 0.38-0.43 | 0.75-1.00 | 0.040 | 0.040 | 0.15-0.35 | 0.80-1.10 | 0.15-0.25 |
Delivery Condition:
Thermal Treatment:
1) A-Annealed
2) N-Normalized
3) QT-Quenched and Tempered
4) SR-Stress relieved or Finish Anneal
Steel Tube Characteristic:
Good concentricity
Good OD and ID tolerance
High Precision
Stable quality
Smooth Roughness
TORICH QUALITY ASSURANCE
Production Processs:
Seamess Hollow Steel Tube and Cold Drawing or Cold Rolling Production, to achieve the target price by mandrel and die, the more accuracy we can make is higher than technical standard ASTM A519.
Method of Tube Forming:
1. Hot-Finished Mechanical Tubing
2. Cold-Worked Mechanical Tubing
3. Rough -Turned Mechanical Tubing
4. Ground Mechanical Tubing
