Seamless Steel Tube

TORICH API 5L 20#, 16Mn, X42, X52 Hot Rolled Seamless Fluid Pipe TORICH API 5L 20#, 16Mn, X42, X52 Hot Rolled Seamless Fluid Pipe Standard: API 5L, API 5CT,ASTM A106,ASTM A53 Size range: OD: 33-610mm WT: 2-20mm Length: 15m max Material: 20#, 16Mn, x42, x52 Usage: Fluid Pipe Characteristic: Good concentricity High Precision Good surface quality Stable quality Good OD and ID tolerance Smooth Roughness TORICH QUALITY ASSURANCE Work shop: Q: Are you trading company or manufacture

GB/T 18984 Low Carbon Hot Rolled Steel Tube for Low Temperature Service Application:Applicable to -45 °C grade ~-100 °C level cryogenic pressure vessel pipe and low temperature heat exchanger pipe seamless steel Size:L--4-12m OD--30-351mm WT--3-25mm Manufacture method:Steel should be smelted with oxygen converter or electric furnace and added outside the furnace Delivery Condition:Normal delivery Processing methods:Hot rolled (expanding) steel pipe--WH cold drawing (rolling)

Seamless Steel Tubes,Cold Drawn or Hot Rolled,GB/T 8163,for Liquid Service,TORICH SPEC: Material:Q295 Q345 10# 20# Q390,Q420,Q460 Size Range OD:4-1200mm WT:0.3-200mm General Length:3-12.5m Tolerance: According to the following tables or customers’ request. Tolerance of the OD &WT: OD Tolerance: Production Method OD Tolerance Hot Rolling(Extrusion) ±1% or ±0.50mm Cold Drawn(Cold Rolled) ±1% or ±0.30mm Tolerance for wall thickness: 1.Wall thickness tolerance of Hot Rolling

GB/T 18984 Low-temperature-service Piping Seamless Steel Tube Application:Applicable to -45 °C grade ~-100 °C level cryogenic pressure vessel pipe and low temperature heat exchanger pipe seamless steel Size:L--4-12m OD--30-351mm WT--3-25mm Manufacture method:Steel should be smelted with oxygen converter or electric furnace and added outside the furnace Delivery Condition:Normal delivery Processing methods:Hot rolled (expanding) steel pipe--WH cold drawing (rolling) Steel pipe

TORICH 1010 1020 10# 20# Carbon Steel Hot rolled Seamless Steel Pipe Tube for Liquid Service GB/T 8163 Steel Grade/Steel Material: Mechanical Properties(longitudinal): Steel Grade Tensile Strength MPa Yield Strength MPa Elongation % s≤16 s>16 no less than 10 335-475 205 195 24 10 410-550 245 235 20 Q295 430-610 295 285 22 Q345 490-665 325 315 21 Test Item Test item 1 Mechenical properties 2 Elongation 3 Impact 4 Flattening Testing 5 Flaring Testing 6 Cold Bend 7 Hydraulic 8 U

ASTM A789 Duplex steel S31803 tube ASTM A789 /A789M Covers Grades of nominal wall thickness, stainless steel tubing for services requiring general corrosion resistance, with particular emphasis on resistance to stress corrosion cracking. These steels are susceptible to embrittlement if used for prolonged periods at elevated temperatures. Chemical Composition UNS Designation Composition, % C Max Mn max P max S max Si max Ni Cr Mo N Cu Others S31803 0.03 2 0.03 0.02 1 4.5-6.5

DUPLEX 2507 STAINLESS STEEL Duplex 2507 (UNS S32750) is a super duplex stainless steel with 25% chromium, 4% molybdenum, and 7% nickel designed for demanding applications which require exceptional strength and corrosion resistance, such as chemical process, petrochemical, and seawater equipment. The steel has excellent resistance to chloride stress corrosion cracking, high thermal conductivity, and a low coefficient of thermal expansion. The high chromium, molybdenum, and

ASTM A240 UNS S32760 Steel Pipe ASTM A240 UNS S32760 Plate is a super duplex grade stainless steel alloy made for specific applications. Super duplex is a grading of duplex steel which is a combination of ferrite and austenitic steel types. By combining the structures of ferrite and austenite steels, a remarkable corrosion resistance along with high tensile strength is achieved. SA 240 UNS S32760 Sheet is used in ships, tanks and containers to deploy in most of the surfaces

ASTM A790 UNS S32750 Welded Pipe ASTM A790 UNS S32750 is a variation of super duplex steel. The duplex steel material is made up of chromium and molybdenum alloy. The duplex has the ferritic and austenitic steel properties in its metallurgic microstructure. This gives the name duplex to the material. The SA 790 UNS S32750 belongs to the super duplex category. There are three groups of duplex, namely the duplex, super duplex and lean duplex. Each of them has their own
