EN 10305-4 E235 E355 +N Carbon Steel Pipe For Hydraulic / Pneumatic Power Systems

Basic Information
Place of Origin: CHINA
Brand Name: TORICH
Certification: UL
Model Number: EN 10305-4 E235 E355
Minimum Order Quantity: 5 Ton
Price: negotiable
Packaging Details: Packing in wooden, hexagonal box or other seaworthy ways
Delivery Time: 30 days
Payment Terms: T/T L/C D/P D/A WesternUnion MoneyGram Others
Supply Ability: 60000 Ton/Year
Detail Information
Technique: Cold Drawn Material: Q215, Q235, Q345, ST35, St45, St52
Surface Treatment: Bright Annealed And Oiled Application: Hydraulic And Pneumatic Power Systems, Hydraulic And Pneumatic Power
High Light:

precision stainless steel tubing

,

seamless carbon steel tube


Product Description

EN 10305-4 Standard Steel Pipe for hydraulic and pneumatic power systems

The steelmaking process of EN10305-4 is at the discretion of the manufacturer and steels shall be fully killed. The tubes shall be manufactured from hot finished seamless tubes by cold drawing. Other suitable methods of cold working are permitted. The tubes shall be delivered in the delivery condition +N which means that after the final cold drawing operation the tubes are normalized in a controlled atmosphere.

EN10305-4
seamless precision bending steel tubes of hydraulic systems
Size: 6-100mm
Delivery condition: +N, +C,+LC, +SR, +A

1. Standard:
EN10305-4
Cold drawn Precision Seamless Steel Pipes

2. Steel Grade:
E215,E235,E355
, other materials upon agreement with customers.

3. Production method:
Cold drawing on the seamless steel tubes, to reach high accuracy on the OD and WT tolerance,
with certain heat treatment to achieve better mechanical properties for bending and pressure purposes

4.Size range:
O.D.:5-100mm W.T.:1-15mm L:max12000mm

5. Packing:
In Hexagonal Bundles, wth anti-rust oil protection, with seaworthy packing

6.Deliver condition:
+NAfter the final cold drawing operation the tubes are normalized in a controlled atmosphere
Please specifiy the final heat treatment when sending the enquiry.

7.Inspection and testing:
Chemical analysis
Tensile test
Flattening test or Drift expanding test
Dimensional inspection
Visual examination
NDT for verification of leaking tightness


                           Chemical composition

Name Number C max Si max Mn max P max S max Al min
E215 1.0212 0.10 0.05 0.70 0.025 0.015 0.025
E235 1.0308 0.17 0.35 1.20 0.025 0.015 -
E355 1.0580 0.22 0.55 1.60 0.025 0.015 -





Permissible deviations of the product analysis from the specified limits given in Table 1

Element Specified limit of the cast analysis % by mass Permissible deviation of the product analysis % by mass
C ≤0.22 +0.02
Si ≤0.55 +0.05
Mn ≤1.60 +0.10
P ≤0.025 +0.005
S ≤0.015 +0.003
Al ≤0.025 -0.005



                   Mechanical properties at room temperature

EN 10305-4 E235 E355 +N Carbon Steel Pipe For Hydraulic / Pneumatic Power Systems 0

                  Summary of Inspection and testing

EN 10305-4 E235 E355 +N Carbon Steel Pipe For Hydraulic / Pneumatic Power Systems 1



                      Requirements for the drift expanding test



Steel grade %increase of the diameter D for
Name Number T≤4mm T>4mm
E215 1.0212 20 15
E235 1.0308 18 12
E355 1.0580 15 10



EN 10305-4 E235 E355 +N Carbon Steel Pipe For Hydraulic / Pneumatic Power Systems 2
