Name: | DIN 2460 Welded Steel Pipe For The Construction Of Water Pipelines | Section Shape: | Round |
---|---|---|---|
Application: | For Water Wall Pannel, Superheat | Technique: | ERW |
High Light: | seamless steel pipe,seamless carbon steel tube |
DIN 2460 Standard applies to welded and seamless types of steel pipes ready for laying, for the connection of water piipelines. The pipe follow the DIN2460 standard especially designed for use in connection with pipes for drinking water pipelines. Nonethelss, it is also applicable to the construction inside building.
Surface: Oiled or black painted to prevent rust
Nominal size | OD | WT | kg/m | Nominal pressure Work certificate2.2 |
80 | 88.9 | 3.2 | 6.76 | 80 |
100 | 114.3 | 3.6 | 9.83 | 63 |
125 | 139.7 | 4 | 13.4 | 63 |
150 | 168.3 | 4.5 | 18.2 | 63 |
200 | 219.1 | 6.3 | 33.1 | 63 |
250 | 273 | 6.3 | 41.4 | 50 |
300 | 323.9 | 7.1 | 55.5 | 50 |
350 | 355.6 | 8 | 68.6 | 50 |
400 | 406.4 | 8.8 | 86.3 | 50 |
500 | 508 | 11 | 135 | 50 |
Minimum average length(m) | Length group (m) |
9 | 3-8 |
8 | 4-11 |
11 | 5.5-14 |
13.6 | 6.5-16.5 |
14.5 | 7.5-18 |
