Name: Bearing Steel Tube GCr15 SAE52100 100Cr6 SUJ-2 S135 SKF3 SKF3S
Brand: TORICH INTERNATIONAL LIMITED
SKU: API, ASTM, BS, DIN, GB, JIS,
Price: 28,750.50 USD
Availability: InStock

Home > products > Automotive Steel Tubes >

Bearing Steel Tube GCr15 SAE52100 100Cr6 SUJ-2 S135 SKF3 SKF3S

low carbon steel tube

steel mechanical tubing

Place of Origin:

China

Brand Name:

Torich

Certification:

GB/T 19001-2008 , ISO 9001:2008 , TS16949

Model Number:

API, ASTM, BS, DIN, GB, JIS,

Request A Quote

Bearing Steel Tube GCr15 SAE52100 100Cr6 SUJ-2 S135 SKF3 SKF3S

Product Details

Grade:

GCr15 SAE52100 100Cr6 SUJ-2 S135 SKF3,SKF3S ECT.

Outer Diameter:

5-114mm

Thickness:

2-20mm

Alloy Or No:

Is Alloy

Section Shape:

Round

Secondary Or Not:

Non-secondary

Application:

Rolling Bearing/rolling Element/Pressure Use

Technique:

Cold Draw Or Cold Worked

Delivery Condition:

Black Surface,ff

Highlight:

low carbon steel tube

steel mechanical tubing

Payment & Shipping Terms

Minimum Order Quantity

5Ton

Price

negotiable

Packaging Details

In in hexagonal bundles or wooden box

Delivery Time

5-8 working days

Payment Terms

L/C, T/T

Supply Ability

6000MT/Year

JIS G3460 Alloy Steel Pipe for low temperature service

Get Best Price

video

Torich Cold Drawn Shock Absorber Tube For Hyduaulic Power System

Get Best Price

video

Cold Drawn Hollow Copper Tube C1100 Air Conditioning Coil Tinned

Get Best Price

video

DIN2391 E235 E355 Cold Drawn Shock Absorber Pipe 10x1 12x1

Get Best Price

86-574-88086983

Contact Now

Product Description

Seamless Cold Worked Bearing Steel Tube

Bearing Steel Tube 100Cr6 , GCr6 , GCr9(SiMn), GCrl5(SiMn) , GSiMnV(Re),GSiMnMoV(Re),GMnMoV(Re)

Specifications

O.D.: 5-144mm W.T.:3.5-20mm L: 0-12000mm according to customer requirements.

Standard
API, ASTM, BS, DIN, GB, JIS,

Grade
GCr15 SAE52100 100Cr6 SUJ-2 S135 SKF3,SKF3S Etc.

Packing & Delivery
1) In bundles or wooden box
2) 30-40 days

Applications
1) Steel ball, roller and collar of large machinery bearing
2) High-hardness and high contact fatigue strength machinery parts with heavy load, such as axis of rotation, blade, stator pump, profiling, sleeve, mandril, etc.

Characteristics
1) Good hardability and high toughness
2) Long fatigue life
3) Medium cold processing plasticity
4) Certain machinability
5) Poor weldability

The Main Technical Parameter of the finished product

Grade	China	ISO	American	Germany	Japan	England
	GCrl5	1	SAE52100	100Cr6	SUJ-2	S135

Chemical Composition	C	Si	Mn	Cr	p	S	Cu	Ni	MO	[O]
	0.95 ~ 1.05	0.15 ~ 0.35	0.25 ~ 0.45	1.40 ~ 1.65	max 0.025	max 0.025	max 0.02	max 0.02	max 0.10	max 10PPM
Surface Hardness	HB179 ~ 207
Decarbonization Deepth	Outer Surface					Inner Surface
	max0.25mm					max0.25mm
Outside Diameter	φ12mm~φ120mm
Wall Thickness	2mm~15mm
Dimensions Tolerance	Outside Diameter		Thickness		Length		Camber		Ellipticity
	+0.4mm -0.00mm		+0.30mm -0.30mm		3~7m		≤1mm/m		≤0.08
Remarks	The details of dimensions and technical needed as requirement
