Carbon And Alloy Steel Mechanical Tubing Seamless Astm A519 For Hydraulic Systems
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 5 tons | Price : | negotiable |
|---|---|---|---|
| Packaging Details : | oil antirust in hexagonal bundles or in carton boxes or in wooden boxes | Delivery Time : | 35-60 days after order confirmed |
| Supply Ability : | 60000 tons per year |
| Place of Origin: | China | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO 9001-2008 ISO 14001 TS16949 DNV SON | Model Number: | EN10305-1 |
|
Detail Information |
|||
| Material: | Carbon And Alloy Steel Grade | Steel Grade: | E 235 E355 Etc |
|---|---|---|---|
| Dimension: | OD6-380mm*WT1-35mm*L:max12000mm | Standard: | EN10305-1 |
| Production Method: | Seamless Cold Drawn/Rolling | Shap: | Round |
| Applications: | Hydrulic Cylinders/Oil Cylinder Tube/Excavator Chains And Parts | Delivery Condition: | +Cc +LCc +SR +Ad +N NBK |
| WT Tolerance: | +/-0.15mm | ||
| High Light: | low carbon steel tube,steel mechanical tubing |
||
Product Description
Precision Steel Tube EN10305-1 Cutting to Specified Length with Hydraulic Cylinder Tubing
Standard: EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes
For Hydraulic Cylinder/Oil Cylinder Tube/Excavator Chains and Parts
Size range: O.D.:6-380mm W.T.:1-35mm L:max12000mm
Steel Grade and Chemical Compositions:
| Steel Grade | C | Si | Mn | P | S | Al | |
| Steel Name | Steel Number | max | max | max | max | max | min |
| E215 | 1.0212 | 0.10 | 0.05 | 0.70 | 0.025 | 0.025 | 0.025 |
| E235 | 1.0308 | 0.17 | 0.35 | 1.20 | 0.025 | 0.025 | - |
| E355 | 1.0580 | 0.22 | 0.55 | 1.60 | 0.025 | 0.025 | - |
| Mechanical properties at room temperature | |||||||||||||
| Steel Grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Nubmer | (+Cc) | (+LCc) | (+SR) | (+Ad) | (+N) NBK | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290-430 | 215 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340-480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450f | 10 | 450 | 22 | 490-630 | 355 | 22 |
aRm: tensile strength; ReH: upper yield strength; A: elongation after fracture
b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm
d For calclulation purposes the following relation is recommended:ReH≥0.5Rm
e For tubes with outside diameter ≤30mm and wall thickness ≤3mm the ReH minimim values are 10Mpa lower than the values given in this Table
f For tubes with outside diameter＞160mm: ReH≥420Mpa
Note: Special steel grade is also available, according to customer request.
Cutting and Packing:
