DOM Steel Tube 30-325mm OD for Mechanical Applications
Product Details
DOM steel tube cold drawn
,DOM steel tube mechanical applications
,DOM steel tube 30-325mm OD
T5 DOM Steel Tube Drawn Over Mandrel Low Carbon Steel Welded Pipe For Mechanical
This product is a Drawn-Over-Mandrel (DOM) steel tube manufactured from low-carbon welded pipe, designed for demanding mechanical applications requiring high precision, uniform mechanical properties, and excellent surface finish. It is cold-drawn over a mandrel to achieve tight tolerances on outside diameter (OD), inside diameter (ID), and wall thickness, resulting in smooth, oxide-free surfaces and superior concentricity. Typical sizes range from very small ODs for precision hydraulic components up to large ODs suitable for structural shafts, with wall thicknesses optimized for strength-to-weight performance. Below is a detailed breakdown of its material characteristics, specifications, chemical and mechanical properties, main features, applicable standards, and application areas.
Material
T5 DOM steel tubing is produced from low-carbon electric-resistance-welded (ERW) “mother tubes” that are cold-drawn over a mandrel to improve dimensional accuracy and surface quality. The base material is typically ASTM A513 Grade 1020 or 1026, selected for its balance of weldability, machinability, and strength.
Specifications
-
Size range (stocked): 3/16″ to 14″ OD; wall thickness from 0.028″ to 0.625″
-
Length: Supplied in random lengths of 17′–24′, with cut-to-length service available
-
Manufacturing process: Electric-resistance-welded → cold-drawn over mandrel (DOM)
-
Grades: Primarily 1020 (OD ≤2″ / wall ≤0.156″) and 1026 (larger or heavier wall)
Chemical Composition
The chemical composition limits for five representative low-carbon DOM grades under ASTM A519 are shown below:
| Grade | C (wt %) | Mn (wt %) | P (max wt %) | S (max wt %) |
|---|---|---|---|---|
| 1018 | 0.15–0.20 | 0.60–0.90 | 0.040 | 0.050 |
| 1020 | 0.18–0.23 | 0.30–0.60 | 0.040 | 0.050 |
| 1022 | 0.18–0.23 | 0.70–1.00 | 0.040 | 0.050 |
| 1026 | 0.22–0.28 | 0.60–0.90 | 0.040 | 0.050 |
| 1030 | 0.28–0.34 | 0.60–0.90 | 0.040 | 0.050 |
Mechanical Performance
Typical mechanical properties for these five grades in the drawn-over-mandrel condition are:
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
|---|---|---|---|
| 1018 | 440 | 370 | 15 |
| 1020 | 420 | 350 | 15 |
| 1022 | 380 | 205 | 25 |
| 1026 | 490 | 415 | 15 |
| 1030 | 525 | 440 | 12 |
Main Features
-
Tight tolerances: Close OD/ID and wall thickness control for precision components
-
Superior surface finish: Smooth, scale-free surfaces ideal for hydraulic and rotating parts
-
Uniform mechanical properties: Cold drawing refines grain structure and increases strength
-
Excellent machinability: Minimal stock allowance required for secondary machining
-
High fatigue resistance: Suitable for cyclic loading in automotive and industrial machinery
Standards
-
ASTM A513 Type 5 (DOM mechanical tubing)
-
ASTM A519 (cold-finished seamless mechanical tubing)
-
EN 10305-3 (cold-drawn precision steel tubes)
-
GOST 8734 (cold-drawn welded steel tubes)
-
JIS G3446 (cold-drawn steel tubes)
-
GB/T 3639 (cold-drawn carbon steel precision tubes)
Application Fields
General Sectors
-
Automotive: Shafts, axles, suspension components
-
Hydraulics: Cylinder barrels, pistons, bushings
-
Industrial Machinery: Gears, bearings, spindles
-
Construction: Structural shafts, linkages
Specific Uses
-
Hydraulic cylinders: Smooth bore for sealing and rod guidance
-
Automotive steering: High concentricity reduces vibration
-
Machine spindles: Enhanced fatigue life under cyclic loads
-
Precision shafts: Tight tolerances ensure accurate alignment
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock,
it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
