ASTM A106 Seamless Carbon Steel Pipe for High-Temperature Service
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO9001 ISO 14001 TS16949
Model Number:
ASTM A106
Trading Properties
Minimum Order Quantity:
1Ton
Price:
800-1000 USD/Ton
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
ASTM A106 Hot Finished Seamless Tubing High-Temperature Seamless Carbon Steel Pipe ASTM A106 is a widely used specification for hot finished seamless carbon steel pipes designed for high-temperature service. These pipes are extensively used in power generation, oil and gas, petrochemical industries, ...
Product Details
Highlight:
ASTM A106 Seamless Steel Tubing
,Hot Finished Seamless Steel Tubing
,High-Temperature Seamless Carbon Pipe
Application:
R High-Temperature Service
Outer Diameter:
20 - 426 Mm,
Thickness:
2 - 100 Mm
Technique:
Cold Drawn,Hot Rolled,Cold Rolled,ERW,Hot Rolled/Cold Drawn
Surface Treatment:
Galvanized,customerized,Copper Coated,Null,polished
Section Shape:
Round,Rectangular
Grade Group:
10#-45#,ST35-ST52,16Mn,A53-A369,Q195-Q345
Length:
6M Or As Requirement,As Customer's Require,8m,5.8m,2.5-8m
Product Description
ASTM A106 Hot Finished Seamless Tubing High-Temperature Seamless Carbon Steel Pipe
ASTM A106 is a widely used specification for hot finished seamless carbon steel pipes designed for high-temperature service. These pipes are extensively used in power generation, oil and gas, petrochemical industries, and other applications requiring high strength and excellent heat resistance.
Material
ASTM A106 pipes are made from carbon steel and manufactured using a hot-finished seamless process. This process ensures a uniform grain structure and superior mechanical properties suitable for high-temperature applications.
Specification
- Standard: ASTM A106/A106M
- Type: Seamless carbon steel pipe
- Manufacturing method: Hot Finished or Hot Rolled
- Grades: A, B, and C
- Application temperature: Suitable for elevated temperature services
- Sizes: NPS 1/8 to NPS 48 (DN 6 to DN 1200)
- Wall thickness: As per ASME B36.10M standard
Chemical Composition
| Element | Grade A (%) | Grade B (%) | Grade C (%) |
|---|---|---|---|
| Carbon (C) | 0.25 max | 0.30 max | 0.35 max |
| Manganese (Mn) | 0.29-1.06 | 0.29-1.06 | 0.29-1.06 |
| Phosphorus (P) | 0.035 max | 0.035 max | 0.035 max |
| Sulfur (S) | 0.035 max | 0.035 max | 0.035 max |
| Silicon (Si) | 0.10-0.35 | 0.10-0.35 | 0.10-0.35 |
Mechanical Properties
| Property | Grade A | Grade B | Grade C |
|---|---|---|---|
| Tensile Strength (MPa) | 415 min | 415 min | 415 min |
| Yield Strength (MPa) | 240 min | 240 min | 260 min |
| Elongation (%) | 30 min | 30 min | 30 min |
| Hardness (HB) | — | — | — |
Key Features
- Manufactured by hot finishing seamless process for enhanced mechanical properties
- Suitable for high-temperature and high-pressure service
- Available in three grades for varying strength and heat resistance requirements
- Compliant with both ASTM and ASME standards
- Resistant to oxidation and scaling at elevated temperatures
- Excellent weldability and machinability
Application
ASTM A106 seamless carbon steel pipes are primarily used in:
- Power plants and boilers for high-temperature steam lines
- Oil and gas transportation
- Petrochemical plants
- Refineries for conveying fluids under pressure and high temperature
- Heat exchangers and condensers
- General high-temperature service applications in industrial plants
Equivalent Grades
| Standard | Equivalent Grade(s) |
|---|---|
| ASME SA106 | SA106 Grade A, B, C |
| API 5L | Grade B |
| EN 10216-2 | P235GH, P245GH |
| DIN EN 10210 | S235JRG1 |
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
·
