12Cr5Mo High Pressure Pipe Seamless Steel Tubes For High-pressure Chemical Fertilizer
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO 9001 ISO14001 TS16949
Model Number:
12Cr5Mo
Trading Properties
Minimum Order Quantity:
1Ton
Price:
Negotiable
Payment Terms:
L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
12Cr5Mo High Pressure Pipe Seamless Steel Tubes for High-Pressure Chemical Fertilizer Material 12Cr5Mo is a high-performance alloy steel known for its excellent strength and resistance to high temperatures and pressures. It is specifically designed for use in high-pressure environments, making it ...
Product Details
Highlight:
Chemical Fertilizer Seamless Steel Tubes
,12Cr5Mo Seamless Steel Tubes
,High Pressure Seamless Steel Tubes
Surface:
Bright Annealing
Payment Terms:
T/T
Manufacture:
Seamless Cold Drawn And Cold Rolling
Heatment:
BKS, NBK,Stress Relieved Annealing
Product:
Precision Steel Pipe
Type:
CDS
Model No:
GB 6479
Delivery Condition:
Cold Drawn, Cold Rolled, Stress Relieved, Annealed, Normalized, Quenched And Tempered
Package:
In Bundles Or As Per Requests
Delivery:
20-30 Days
Grade:
12Cr5Mo
Heart Treatment:
Annealed, Bright Annealed
Production Method:
Seamless, ERW
Application:
High-pressure Chemical Fertilizer
Standard:
ASTM,DIN,GB,JIS,API
Thickness:
0.1mm-60mm
Certification:
API,CE,ISO,ISO9001-2008,ISO9001
Technique:
Cold Drawn,Hot Rolled,Cold Rolled,ERW,Hot Rolled/Cold Drawn
Surface Treatment:
Galvanized,customerized
Alloy Or Not:
Non-alloy,Is Alloy,NON -alloy
standard2:
GB 6479
Section Shape:
Round,Rectangular
Outer Diameter(Round):
17 - 660 Mm
Special Pipe:
Thick Wall Pipe,API Pipe,Precision Steel Tube,precision Seamless Pipe,cold Drawn
Secondary Or Not:
Non-secondary
Length:
6M Or As Requirement
Product Name:
Steel Tubes,Cold Drawn Precision Round Carbon Steel Tube
Material:
Steel
Product Description
12Cr5Mo High Pressure Pipe Seamless Steel Tubes for High-Pressure Chemical Fertilizer
Material
12Cr5Mo is a high-performance alloy steel known for its excellent strength and resistance to high temperatures and pressures. It is specifically designed for use in high-pressure environments, making it ideal for applications in the chemical fertilizer industry.
Specification
12Cr5Mo seamless steel tubes are manufactured to meet stringent specifications, ensuring their suitability for high-pressure applications. These tubes are typically produced according to standards such as ASTM, ASME, and EN, which dictate their dimensions, mechanical properties, and chemical composition.
Key Features
- High Strength: Capable of withstanding high pressures and temperatures.
- Corrosion Resistance: Excellent resistance to oxidation and corrosion, even in harsh chemical environments.
- Durability: Long service life due to its robust material properties.
- Versatility: Suitable for various high-pressure applications beyond chemical fertilizers.
Chemical Composition
The chemical composition of 12Cr5Mo steel is crucial for its performance. Below is a typical composition table:
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.08 - 0.15 |
| Silicon (Si) | 0.10 - 0.50 |
| Manganese (Mn) | 0.30 - 0.60 |
| Phosphorus (P) | ≤ 0.035 |
| Sulfur (S) | ≤ 0.035 |
| Chromium (Cr) | 4.00 - 6.00 |
| Molybdenum (Mo) | 0.45 - 0.65 |
Mechanical Properties
The mechanical properties of 12Cr5Mo steel tubes are essential for their performance in high-pressure applications. Here is a typical properties table:
| Property | Value |
|---|---|
| Tensile Strength | ≥ 485 MPa |
| Yield Strength | ≥ 275 MPa |
| Elongation | ≥ 20% |
| Hardness | ≤ 179 HB |
Steel Grade
12Cr5Mo is often classified under various steel grades depending on the standards and specifications it adheres to. Common designations include ASTM A335 P5 and EN 10216-2 12CrMo195.
Application
12Cr5Mo seamless steel tubes are primarily used in:
- Chemical Fertilizer Production: High-pressure piping systems for transporting chemicals.
- Petrochemical Industry: High-temperature and high-pressure environments.
- Power Generation: Boiler tubes and heat exchangers.
- Oil and Gas: High-pressure pipelines and processing equipment.
Possible Alternative Grades
While 12Cr5Mo is highly effective, alternative grades may be considered based on specific requirements:
- 10CrMo910: Offers similar properties with slight variations in chemical composition.
- 15CrMo: Provides higher chromium content for enhanced corrosion resistance.
- T91: Known for its superior strength and creep resistance at elevated temperatures.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
