DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures

Name: DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures
Brand: TORICH INTERNATIONAL LIMITED
SKU: DIN 17177
Price: 3,501.00 USD
Availability: InStock

Brand Name:	TORICH
Model Number:	DIN 17177
MOQ:	1 Ton
Price:	Negotiable
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:	60000 Ton/Tons per Year

Detail Information

Product Description

Detail Information

Place of Origin:

Zhejiang/China

Certification:

ISO 9001 ISO14001 TS16949

Section Shape:

Elevated Temperatures

Secondary Or Not:

Non-secondary

Technique:

ERW

Thickness:

0.4 - 50 Mm

Surface Treatment:

Galvanized

Alloy Or Not:

Is Alloy

Standard:

ASTM,GB,JIS,BS

Grade:

St37.8 St42.8 15Mo3

Grade Group:

ST35-ST52

Special Pipe:

Precision Tube

Length:

1-12m/as Customers' Requests

Outer Diameter(round):

20 - 677 Mm

Product Name:

Galvanized Square Steel Pipe/Tube

Packaging Details:

In bundles or in wooden boxes.

Supply Ability:

60000 Ton/Tons per Year

Highlight:

Electric Resistance Welded Steel Pipe

DIN 17177 St37.8 Electric Pressure Pipe

Electric Pressure Pipe For Elevated Temperatures

Product Description

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 0

DIN 17177 St37.8 St42.8 15Mo3 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures

Material

DIN 17177 is a standard that specifies the requirements for electric resistance welded (ERW) steel pipes used for elevated temperature applications. The pipes are designed to withstand high pressures and temperatures, making them suitable for various industrial applications.

Specification

The standard outlines the specifications for the manufacturing process, dimensions, tolerances, and testing methods for the steel pipes. It ensures that the pipes meet the necessary quality and performance criteria for use in critical applications.

Key Features

High Strength: Designed to withstand high pressures and temperatures.
Welded Construction: Electric resistance welding provides a strong and reliable joint.
Corrosion Resistance: Suitable for various environments, depending on the coating and treatment.
Versatile Applications: Used in power plants, chemical industries, and other high-temperature applications.

Chemical Composition

Element	St37.8 (%)	St42.8 (%)	15Mo3 (%)
Carbon (C)	0.17 max	0.22 max	0.12-0.20
Manganese (Mn)	1.20-1.60	1.20-1.60	0.40-0.70
Phosphorus (P)	0.035 max	0.035 max	0.025 max
Sulfur (S)	0.035 max	0.035 max	0.025 max
Chromium (Cr)	-	-	0.90-1.20
Molybdenum (Mo)	-	-	0.30-0.50

Mechanical Properties

Property	St37.8	St42.8	15Mo3
Yield Strength (MPa)	235	245	250
Tensile Strength (MPa)	360-510	360-510	400-550
Elongation (%)	22 min	22 min	20 min
Hardness (HB)	140 max	140 max	160 max

Steel Grade

St37.8: Low carbon steel suitable for moderate temperature applications.
St42.8: Higher carbon content for improved strength and temperature resistance.
15Mo3: Alloy steel with molybdenum, designed for high-temperature applications.

Application

These steel pipes are primarily used in:

Power generation plants
Chemical processing industries
Oil and gas industries
Boiler and pressure vessel manufacturing

Possible Alternative Grades

P235GH: Similar properties, suitable for pressure applications.
P265GH: Higher strength, used in similar applications.
A106 Grade B: Commonly used for high-temperature service.

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 1

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 2

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 4

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 6

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 7

TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and

trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and

credibility among domestic and foreign customers.

The company's production plant covers an area of over 10,000 square meters, with an annual production

capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.

The group holds shares in more than ten domestic production entities, whose main products include

seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.

Over the past 30 years, the company has been gradually developing new technologies and materials to meet

the growing needs of customers and various diversified needs, exporting to more than 56 countries and still

increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 8

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 9

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 10

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 11

DIN 17177 St37.8 Electric Resistance Welded Steel Pipe Electric Pressure Pipe For Elevated Temperatures 12

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.

Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
