ASTM A512 1010 Cold Drawn Tube Buttweld Carbon Steel DOM Steel Tube For Mechanical
Product Details
Buttweld DOM Steel Tube
,ASTM A512 DOM Steel Tube
,1010 DOM Steel Tube
ASTM A512 1008 1010 1012 1015 1016 Cold Drawn Tube Buttweld Carbon Steel DOM Steel Tube
Introduction
The ASTM A512 specification covers cold drawn, buttweld carbon steel tubes that are used in various mechanical applications. These tubes are characterized by their high strength, excellent machinability, and good weldability, making them suitable for a wide range of industrial uses.
Material Specification
ASTM A512 specifies the requirements for cold drawn, buttweld carbon steel tubes. The tubes are produced from hot-rolled steel and are cold drawn to achieve precise dimensions and improved mechanical properties.
Chemical Composition
The following table outlines the chemical composition of the various grades specified under ASTM A512:
| Grade | Carbon (C) | Manganese (Mn) | Phosphorus (P) | Sulfur (S) |
|---|---|---|---|---|
| 1008 | 0.08 max | 0.30 - 0.60 | 0.04 max | 0.05 max |
| 1010 | 0.10 max | 0.30 - 0.60 | 0.04 max | 0.05 max |
| 1012 | 0.12 max | 0.30 - 0.60 | 0.04 max | 0.05 max |
| 1015 | 0.15 max | 0.30 - 0.60 | 0.04 max | 0.05 max |
| 1016 | 0.16 max | 0.30 - 0.60 | 0.04 max | 0.05 max |
Mechanical Properties
The mechanical properties of the ASTM A512 tubes are critical for their performance in various applications. The following table summarizes the key mechanical properties for each grade:
| Grade | Yield Strength (ksi) | Tensile Strength (ksi) | Elongation (%) |
|---|---|---|---|
| 1008 | 30 | 50 - 70 | 20 |
| 1010 | 33 | 60 - 80 | 20 |
| 1012 | 36 | 65 - 85 | 20 |
| 1015 | 40 | 70 - 90 | 20 |
| 1016 | 42 | 75 - 95 | 20 |
Applications
ASTM A512 cold drawn tubes are widely used in various mechanical applications due to their strength and durability. Common applications include:
- Automotive Components: Used in the manufacturing of frames, axles, and other structural components.
- Machinery: Employed in the production of hydraulic cylinders and other machinery parts.
- Construction: Utilized in scaffolding, support structures, and other construction applications.
- Pipelines: Suitable for transporting fluids and gases in industrial settings.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
