EN 10025-2 S235JR Structural Steel Pipe Hot Rolled Non-Alloy Structural Steel Tube For building
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO 9001 ISO14001 TS16949
Model Number:
EN 10025-2
Trading Properties
Minimum Order Quantity:
1 Ton
Price:
Negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
EN 10025-2 S235JR S235J0 S235J2 S275JR S275J0 Structural Steel Pipe Introduction EN 10025-2 is a European standard that specifies the technical delivery conditions for hot-rolled non-alloy structural steel products. This standard covers various grades of structural steel, including S235JR, S235J0, ...
Product Details
Highlight:
Hot Rolled Structural Steel Pipe
,Building Structural Steel Pipe
,Non Alloy Structural Steel Tube
Application:
Building
Standard:
DIN,GB,JIS
Thickness:
0.1mm-60mm
Certification:
CE,ISO,ISO9001-2008
Technique:
Cold Drawn,Hot Rolled,Cold Rolled
Surface Treatment:
Customerized
Grade:
S235JR S235J0 S235J2 S275JR S275J0
Alloy Or Not:
Non-alloy
standard2:
EN 10025-2
Section Shape:
Round,Rectangular
Outer Diameter(Round):
17 - 660 Mm
Special Pipe:
Precision Seamless Pipe,cold Drawn
Secondary Or Not:
Non-secondary
Length:
6M Or As Requirement
Product Name:
Cold Drawn Precision Round Carbon Steel Tube
Type:
Seamless
Material:
Steel
Product Description
EN 10025-2 S235JR S235J0 S235J2 S275JR S275J0 Structural Steel Pipe
Introduction
EN 10025-2 is a European standard that specifies the technical delivery conditions for hot-rolled non-alloy structural steel products. This standard covers various grades of structural steel, including S235JR, S235J0, S235J2, S275JR, and S275J0, which are widely used in construction and engineering applications.
Material Specification
The structural steel grades specified in EN 10025-2 are characterized by their yield strength, tensile strength, and impact toughness. These properties make them suitable for various structural applications, including buildings, bridges, and other infrastructure projects.
Key Features
- Hot Rolled: The steel is processed at high temperatures, which enhances its ductility and workability.
- Non-Alloy: These grades do not contain significant amounts of alloying elements, making them cost-effective.
- Good Weldability: The low carbon content allows for easy welding and fabrication.
- Versatile Applications: Suitable for a wide range of structural applications.
Chemical Composition
| Grade | C (%) | Si (%) | Mn (%) | P (%) | S (%) | N (%) |
|---|---|---|---|---|---|---|
| S235JR | 0.17 | 0.55 | 1.40 | 0.045 | 0.045 | 0.012 |
| S235J0 | 0.17 | 0.55 | 1.40 | 0.045 | 0.045 | 0.012 |
| S235J2 | 0.17 | 0.55 | 1.40 | 0.045 | 0.045 | 0.012 |
| S275JR | 0.20 | 0.55 | 1.60 | 0.045 | 0.045 | 0.012 |
| S275J0 | 0.20 | 0.55 | 1.60 | 0.045 | 0.045 | 0.012 |
Mechanical Properties
| Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation (%) | Impact Energy (J) at -20°C |
|---|---|---|---|---|
| S235JR | 235 | 360-510 | ≥ 26 | 27 |
| S235J0 | 235 | 360-510 | ≥ 26 | 27 |
| S235J2 | 235 | 360-510 | ≥ 26 | 40 |
| S275JR | 275 | 430-580 | ≥ 22 | 27 |
| S275J0 | 275 | 430-580 | ≥ 22 | 27 |
Steel Grade
- S235JR: General structural steel with a minimum yield strength of 235 MPa.
- S235J0: Similar to S235JR but with improved impact properties at lower temperatures.
- S235J2: Offers higher impact resistance at even lower temperatures.
- S275JR: Higher yield strength of 275 MPa, suitable for more demanding applications.
- S275J0: Enhanced impact properties compared to S275JR.
Application
These structural steel grades are commonly used in:
- Construction of buildings and bridges
- Manufacturing of structural components
- Heavy machinery and equipment
- General engineering applications
Possible Alternative Grades
- S355: A higher strength grade that can be used in applications requiring greater load-bearing capacity.
- S420: Suitable for high-strength applications, offering improved mechanical properties.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
