ASTM A1110 Grade A Seamless Steel Tube Cold-Formed Carbon Steel Structural Tubing
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO 9001 ISO14001 TS16949
Model Number:
ASTM A1110
Trading Properties
Minimum Order Quantity:
1 Ton
Price:
Negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
ASTM A1110 Grade A Grade B Seamless Steel Tube Cold-Formed Carbon Steel Structural Tubing Material and Specification ASTM A1110 is a specification for cold-formed carbon steel structural tubing. This standard covers seamless steel tubes that are used in structural applications. The tubes are ...
Product Details
Highlight:
Cold-Formed Seamless Steel Tube
,Carbon Steel Structural Tubing
,ASTM A1110 Seamless Steel Tube
Thickness:
0.4 - 50 Mm
Standard:
ASTM
Grade:
GradeA GradeB
Application:
Structure Pipe
Section Shape:
Round,Square
Alloy Or Not:
Is Alloy
Technique:
Hot Rolled,Cold Drawn,Cold Rolled,welded And Seamless Steel Pipe
Secondary Or Not:
Non-secondary
Outer Diameter(Round):
22 - 530 Mm
Special Pipe:
Precision Seamless Pipe,seamless Stainless Steel Tube
Certification:
ISO
Material:
Carbon Steel
Length:
5-12M Or As Your Requirement
Shape:
Square. Rectangular.Round
Product Name:
Seamless Steel Tube
Surface:
Customers't Requirement
Product Description
ASTM A1110 Grade A Grade B Seamless Steel Tube Cold-Formed Carbon Steel Structural Tubing
Material and Specification
ASTM A1110 is a specification for cold-formed carbon steel structural tubing. This standard covers seamless steel tubes that are used in structural applications. The tubes are designed to provide high strength and durability, making them suitable for various construction and engineering projects.
Key Features
- Seamless Construction: Ensures uniformity and strength throughout the tube.
- Cold-Formed: Enhances mechanical properties and surface finish.
- Versatile Applications: Suitable for a wide range of structural applications.
- High Strength: Provides excellent load-bearing capabilities.
Chemical Composition
The chemical composition of ASTM A1110 Grade A and Grade B is critical for determining the mechanical properties and performance of the steel tubes. Below is a table summarizing the typical chemical composition for both grades.
| Element | Grade A (%) | Grade B (%) |
|---|---|---|
| Carbon (C) | 0.20 max | 0.25 max |
| Manganese (Mn) | 0.60 - 0.90 | 0.60 - 0.90 |
| Phosphorus (P) | 0.04 max | 0.04 max |
| Sulfur (S) | 0.05 max | 0.05 max |
| Silicon (Si) | 0.10 - 0.40 | 0.10 - 0.40 |
Mechanical Properties
The mechanical properties of ASTM A1110 Grade A and Grade B are essential for assessing their suitability for structural applications. The following table presents the typical mechanical properties for both grades.
| Property | Grade A | Grade B |
|---|---|---|
| Yield Strength (ksi) | 36 | 46 |
| Tensile Strength (ksi) | 58 | 65 |
| Elongation (%) | 20 | 20 |
| Hardness (HB) | 120 max | 130 max |
Steel Grade
- Grade A: Designed for lower strength applications, suitable for general structural use.
- Grade B: Offers higher strength and is ideal for more demanding structural applications.
Application
ASTM A1110 seamless steel tubes are widely used in various applications, including:
- Structural support in buildings and bridges
- Manufacturing of machinery and equipment
- Automotive and transportation components
- Oil and gas industry piping systems
Possible Alternative Grades
While ASTM A1110 Grade A and Grade B are popular choices, there are alternative grades that may be considered based on specific requirements:
- ASTM A500: A standard specification for cold-formed welded and seamless carbon steel structural tubing.
- ASTM A53: A specification for pipe suitable for welding and bending, often used in structural applications.
- ASTM A252: A specification for welded and seamless steel pipe piles.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
