ASME B36.10M Grade B Welded Steel Tube Wrought Steel Pipe For General Applications
Basic Properties
Place of Origin:
Zhejiang/China
Brand Name:
TORICH
Certification:
ISO 9001 ISO14001 TS16949
Model Number:
ASME B36.10M
Trading Properties
Minimum Order Quantity:
1 Ton
Price:
Negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
60000 Ton/Tons per Year
Product Summary
ASME B36.10M Grade B Welded Steel Tube Wrought Steel Pipe For General Applications Introduction ASME B36.10M is a standard that specifies the dimensions and tolerances for welded and seamless wrought steel pipes. Grade B is a common designation for pipes used in various general applications, ...
Product Details
Highlight:
General Applications Welded Steel Tube
,Wrought Steel Pipe Welded Steel Tube
,ASME B36.10M Welded Steel Tube
Section Shape:
Round/Square/Rectangular/Oval.etc
Secondary Or Not:
Non-secondary
Technique:
ERW,Hot Rolled,Cold Rolled
Thickness:
0.4 - 50 Mm
Application:
General Applications
Surface Treatment:
Galvanized
Alloy Or Not:
Non-alloy
Standard:
ASTM
Grade:
20#
Grade Group:
10#-45#
Special Pipe:
Precision Tube
Length:
1-12m/as Customers' Requests
Surface:
Galvanized Coated
Outer Diameter(Round):
20 - 677 Mm
Product Name:
ERW Steel Pipes,galvanized Round Pipe
Product Description
ASME B36.10M Grade B Welded Steel Tube Wrought Steel Pipe For General Applications
Introduction
ASME B36.10M is a standard that specifies the dimensions and tolerances for welded and seamless wrought steel pipes. Grade B is a common designation for pipes used in various general applications, including construction, manufacturing, and transportation of fluids and gases. This article will cover the material specifications, key features, chemical composition, mechanical properties, applications, and possible alternative grades of ASME B36.10M Grade B welded steel tubes.
Material Specification
ASME B36.10M Grade B pipes are typically made from carbon steel, which provides a good balance of strength, ductility, and weldability. The standard outlines the requirements for the manufacturing process, including the methods of welding and testing.
Key Features
- Durability: Designed to withstand high pressure and temperature.
- Versatility: Suitable for a wide range of applications.
- Weldability: Easily welded using standard welding techniques.
- Standardization: Adheres to ASME specifications, ensuring quality and reliability.
Chemical Composition
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.18 max |
| Manganese (Mn) | 0.60 - 0.90 |
| Phosphorus (P) | 0.04 max |
| Sulfur (S) | 0.05 max |
| Silicon (Si) | 0.10 - 0.40 |
| Iron (Fe) | Balance |
Mechanical Properties
| Property | Value |
|---|---|
| Yield Strength (min) | 35,000 psi (240 MPa) |
| Tensile Strength (min) | 60,000 psi (415 MPa) |
| Elongation (min) | 20% |
| Hardness (Brinell) | 120 HB max |
Steel Grade
- Grade B: This grade is commonly used for pipes that require moderate strength and good weldability. It is suitable for various applications, including water, gas, and oil transportation.
Application
ASME B36.10M Grade B welded steel tubes are widely used in:
- Construction: Structural applications in buildings and bridges.
- Manufacturing: Equipment and machinery fabrication.
- Oil and Gas: Pipelines for transporting crude oil and natural gas.
- Water Supply: Distribution systems for potable water.
Possible Alternative Grades
While Grade B is widely used, there are alternative grades that may be suitable depending on specific requirements:
- Grade A: Lower strength, used for less demanding applications.
- Grade C: Higher strength, suitable for more demanding environments.
- API 5L: A specification for line pipes used in the oil and gas industry.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
