ASTM A501 Gr.A Gr.B Seamless Carbon Steel Tube for Construction
Basic Properties
Place of Origin:
China,zhejiang
Brand Name:
TORICH
Certification:
ISO9001, ISO14001, TS16949
Model Number:
ASTM A501
Trading Properties
Minimum Order Quantity:
1Tons
Price:
Negotiable
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
5000Tons per Year
Product Summary
ASTM A501 Gr.A Gr.B Hot Formed Structural Tubing Seamless Carbon Steel Tube for Construction Introduction ASTM A501 is a specification that covers hot-formed structural tubing made from carbon steel. This type of tubing is widely used in construction and structural applications due to its strength ...
Product Details
Highlight:
ASTM A501 Seamless Carbon Steel Tube
,Hot Formed Seamless Carbon Steel Tube
,Construction Seamless Carbon Steel Tube
standard2:
ASTM A501
Thickness:
0.4 - 50 Mm
Standard:
ASTM
Grade:
Grade A; Grade B
Application:
Structure Pipe
Section Shape:
Round
Alloy Or Not:
Is Alloy
Technique:
Hot Rolled,Cold Drawn,Cold Rolled
Secondary Or Not:
Non-secondary
Outer Diameter(Round):
8 - 100 Mm
Special Pipe:
Precision Seamless Pipe,seamless Stainless Steel Tube
Certification:
API,CE,ISO,BSI
Length:
5-12M Or As Your Requirement
Usage:
Construction Structure
Shape:
Square. Rectangular.Round
Product Name:
Seamless Steel Tube
Surface:
Customers't Requirement
Product Description
ASTM A501 Gr.A Gr.B Hot Formed Structural Tubing Seamless Carbon Steel Tube for Construction
Introduction
ASTM A501 is a specification that covers hot-formed structural tubing made from carbon steel. This type of tubing is widely used in construction and structural applications due to its strength and durability. The specification includes two grades: Gr.A and Gr.B, each with distinct mechanical properties and chemical compositions.
Material
The material used in ASTM A501 tubing is carbon steel, which is known for its excellent strength-to-weight ratio and versatility in various construction applications.
Specification
ASTM A501 outlines the requirements for hot-formed structural tubing, including dimensions, tolerances, and mechanical properties. The tubing is typically produced in round, square, or rectangular shapes.
Key Features
- High Strength: Provides excellent load-bearing capabilities.
- Versatility: Suitable for various structural applications.
- Seamless Design: Ensures uniform strength and eliminates weak points.
- Hot Forming Process: Enhances mechanical properties and allows for complex shapes.
Chemical Composition
| Element | Gr.A (%) | Gr.B (%) |
|---|---|---|
| Carbon (C) | 0.26 max | 0.26 max |
| Manganese (Mn) | 0.60-0.90 | 0.60-0.90 |
| Phosphorus (P) | 0.04 max | 0.04 max |
| Sulfur (S) | 0.05 max | 0.05 max |
| Silicon (Si) | 0.10-0.40 | 0.10-0.40 |
Mechanical Properties
| Property | Gr.A | Gr.B |
|---|---|---|
| Yield Strength (ksi) | 35 min | 42 min |
| Tensile Strength (ksi) | 58-70 | 58-75 |
| Elongation (%) | 20 min | 20 min |
| Hardness (Rockwell) | B70 max | B70 max |
Steel Grade
- Gr.A: Lower yield strength, suitable for less demanding applications.
- Gr.B: Higher yield strength, ideal for more demanding structural applications.
Application
ASTM A501 structural tubing is commonly used in:
- Building frames
- Bridges
- Towers
- Heavy equipment
- Agricultural structures
Possible Alternative Grades
- ASTM A500: Another specification for cold-formed structural tubing.
- ASTM A53: Standard specification for pipe, which can be used in similar applications.
- ASTM A252: Specification for welded and seamless steel pipe piles.
TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.
The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.
The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.
Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
