ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose

Brand Name: TORICH
Model Number: ASTM A1053
MOQ: 1 Ton
Price: Negotiable
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60000 Ton/Tons per Year
Detail Information
Place of Origin:
Zhejiang/China
Certification:
ISO 9001 ISO14001 TS16949
Application:
General Purpose
Standard:
ASTM
Thickness:
0.1mm-60mm
Certification:
API,ISO9001-2008
Technique:
Cold Drawn,Hot Rolled,Cold Rolled,Hot Rolled/Cold Drawn
Surface Treatment:
Customerized
Grade:
S41003 Grade50 Schedule 5S Schedule 10S Schedule 40S Schedule 80S
Alloy Or Not:
Non-alloy,Is Alloy
Section Shape:
Round,Rectangular
Outer Diameter(round):
30 - 325 Mm
Special Pipe:
Precision Seamless Pipe
Secondary Or Not:
Non-secondary
Length:
As Customer's Require
Product Name:
Cold Drawn Precision Round Carbon Steel Tube
Type:
Welded Or Seamless Tube
Steel Grade:
200series 300series
Outer Diameter:
6-630mm
Material:
Steel
Packaging Details:
In bundles or in wooden boxes.
Supply Ability:
60000 Ton/Tons per Year
Highlight:

General Purpose Stainless Steel Tube

,

Welded Ferrltlc-Martensitlc Stainless Steel Tube

,

ASTM A1053 Stainless Steel Tube

Product Description

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 0

ASTM A1053 S41003 Grade 50 Stainless Steel Tube Welded Ferritic-Martensitic Stainless Steel Pipe for General Purpose

Introduction

ASTM A1053 S41003 Grade 50 is a type of stainless steel tube that is specifically designed for general-purpose applications. This material is characterized by its ferritic-martensitic structure, which provides a balance of strength and corrosion resistance. It is commonly used in various industries, including oil and gas, chemical processing, and power generation.

Material Specification

The ASTM A1053 specification covers the requirements for welded ferritic-martensitic stainless steel pipes. These pipes are manufactured to meet specific mechanical and chemical properties, ensuring their suitability for a wide range of applications.

Key Features

  • Corrosion Resistance: Offers good resistance to oxidation and corrosion.
  • High Strength: Provides excellent mechanical properties, making it suitable for high-stress applications.
  • Weldability: Designed for ease of welding, allowing for versatile fabrication options.
  • Temperature Resistance: Maintains mechanical properties at elevated temperatures.

Chemical Composition

Element Composition (%)
Carbon (C) ≤ 0.03
Manganese (Mn) 0.50 - 1.00
Phosphorus (P) ≤ 0.025
Sulfur (S) ≤ 0.015
Silicon (Si) ≤ 1.00
Chromium (Cr) 11.0 - 13.0
Nickel (Ni) 0.50 - 1.50
Molybdenum (Mo) 0.00 - 0.50
Iron (Fe) Balance

Mechanical Properties

Property Value
Yield Strength (min) 345 MPa (50 ksi)
Tensile Strength (min) 620 MPa (90 ksi)
Elongation (min) 20%
Hardness (max) 200 HB

Steel Grade

  • S41003 Grade 50: This grade is specifically formulated to meet the requirements of ASTM A1053, ensuring that it possesses the necessary mechanical and chemical properties for general-purpose applications.

Application

The ASTM A1053 S41003 Grade 50 stainless steel tube is widely used in:

  • Oil and gas pipelines
  • Chemical processing equipment
  • Power generation systems
  • Structural applications in construction

Possible Alternative Grades

While ASTM A1053 S41003 Grade 50 is a robust choice for many applications, there are alternative grades that may also be considered based on specific requirements:

  • ASTM A312 TP 304: Austenitic stainless steel with excellent corrosion resistance.
  • ASTM A790 S31803: Duplex stainless steel offering high strength and corrosion resistance.
  • ASTM A276 410: Martensitic stainless steel suitable for applications requiring high strength.



ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 1

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 2     ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 3



ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 4     ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 5



ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 6

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 7



TORICH Group, an one-stop service provider of raw materials engaged in raw material production, R&D and
trade, has 30+ years of experience in the market, exported to 56 +countries, and won good reputation and
credibility among domestic and foreign customers.

The company's production plant covers an area of over 10,000 square meters, with an annual production
capacity of 50,000 tons of materials and a comprehensive trading and warehousing capacity of 100,000 tons, which can satisfy customers' personalized needs for raw materials in terms of diversity and timeliness.

The group holds shares in more than ten domestic production entities, whose main products include
seamless steel pipes ( carbon steel and stainless steel), welded pipes ( carbon steel and stainless steel), pipe fittings ( carbon steel and stainless steel), titanium (titanium tubes, titanium rods, titanium cakes, titanium plates, etc.), aluminum (aluminum tubes, aluminum rods, aluminum die casting, aluminum casting, CNC machining), and CNC deep processing of metal materials such as tubes, rods, and casting parts.

Over the past 30 years, the company has been gradually developing new technologies and materials to meet
the growing needs of customers and various diversified needs, exporting to more than 56 countries and still
increasing the number of exporting countries, aiming to help customers to solve the demand for raw materials, and to facilitate one-stop purchasing for customers.

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 8

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 9

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 10

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 11

ASTM A1053 S41003 Stainless Steel Tube Welded Ferrltlc-Martensitlc Stainless Steel Pipe For General Purpose 12

Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.



Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.

If you have another question, pls feel free to contact with me.
