ASTM A270 316L Bright Stainless Steel Sanitary Tubing Pipe For Medical Field
Product Details
Medical Field Stainless Steel Sanitary Tubing
,ASTM A270 Stainless Steel Sanitary Tubing
,316L Stainless Steel Sanitary Tubing
ASTM A270 TP304 TP316 2205 2507 2003 Stainless Steel Sanitary Tubing Stainless Steel Bright Sanitary Pipe For Medical Field
Introduction
In the medical field, the use of high-quality materials is crucial to ensure the ety and reliability of various applications. ASTM A270 TP304, TP316, 2205, 2507, and 2003 stainless steel sanitary tubing, also known as stainless steel bright sanitary pipe, is widely used in medical equipment and facilities. This article will provide an overview of the material, specification, key features, chemical composition, mechanical properties, steel grade, application, and possible alternative grades of this stainless steel sanitary tubing.
Material and Specification
ASTM A270 TP304, TP316, 2205, 2507, and 2003 stainless steel sanitary tubing is manufactured according to the ASTM A270 standard, which specifies the requirements for seamless and welded austenitic and ferritic/austenitic stainless steel sanitary tubing intended for use in the dairy and food industry, as well as in biotechnology, pharmaceuticals, and other sanitary applications.
The tubing is available in various sizes, ranging from 1/2 inch to 8 inches in outside diameter, with different wall thicknesses. It is commonly supplied in lengths of 20 feet, but custom lengths can also be provided.
Key Features
The stainless steel sanitary tubing offers several key features that make it suitable for medical applications:
-
Corrosion Resistance: The high-quality stainless steel used in this tubing provides excellent resistance to corrosion, ensuring the integrity and longevity of medical equipment and facilities.
-
Hygienic Design: The tubing is designed to meet strict hygienic standards, making it suitable for applications where cleanliness and sterility are essential, such as in pharmaceutical and biotechnology industries.
-
Smooth Surface: The bright surface finish of the tubing minimizes the risk of bacterial adhesion, facilitating easy cleaning and maintenance.
-
High Strength: The stainless steel material used in this tubing offers good mechanical properties, providing strength and durability for demanding medical applications.
Chemical Composition
The following table presents the chemical composition of ASTM A270 TP304, TP316, 2205, 2507, and 2003 stainless steel sanitary tubing:
| Grade | C | Mn | P | S | Si | Ni | Cr | Mo | N |
|---|---|---|---|---|---|---|---|---|---|
| TP304 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.030 | ≤1.00 | 8.0-11.0 | 18.0-20.0 | - | - |
| TP316 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.030 | ≤1.00 | 10.0-14.0 | 16.0-18.0 | 2.00-3.00 | - |
| 2205 | ≤0.03 | ≤2.00 | ≤0.030 | ≤0.020 | ≤1.00 | 4.5-6.5 | 22.0-23.0 | 3.0-3.5 | 0.14-0.20 |
| 2507 | ≤0.03 | ≤1.20 | ≤0.035 | ≤0.020 | ≤0.80 | 6.0-8.0 | 24.0-26.0 | 3.0-5.0 | 0.24-0.32 |
| 2003 | ≤0.08 | ≤2.00 | ≤0.045 | ≤0.030 | ≤1.00 | 1.0-2.0 | 17.0-19.0 | 2.0-3.0 | - |
Mechanical Properties
The mechanical properties of ASTM A270 TP304, TP316, 2205, 2507, and 2003 stainless steel sanitary tubing are as follows:
| Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) | Hardness (HB) |
|---|---|---|---|---|
| TP304 | ≥515 | ≥205 | ≥35 | ≤192 |
| TP316 | ≥515 | ≥205 | ≥35 | ≤192 |
| 2205 | ≥620 | ≥450 | ≥25 | ≤290 |
| 2507 | ≥800 | ≥550 | ≥15 | ≤310 |
| 2003 | ≥515 | ≥205 | ≥35 | ≤192 |
Steel Grade and Application
The steel grades covered by ASTM A270 TP304, TP316, 2205, 2507, and 2003 stainless steel sanitary tubing are widely used in the medical field for various applications, including:
- Medical equipment manufacturing
- Pharmaceutical industry
- Biotechnology industry
- Food processing industry
- Dairy industry
- Laboratory equipment
Possible Alternative Grades
While ASTM A270 TP304, TP316, 2205, 2507, and 2003 stainless steel sanitary tubing are widely used and trusted in the medical field, there are alternative grades available depending on specific requirements. Some possible alternative grades include:
- TP321: Offers improved resistance to intergranular corrosion and higher strength at elevated temperatures.
- TP310: Provides excellent high-temperature oxidation resistance and resistance to sulfidation.
- TP904L: Known for its exceptional resistance to corrosion in a wide range of environments, including those containing sulfuric acid.
It is important to consult with experts or refer to specific standards and regulations to determine the most suitable alternative grade for a particular medical application.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
