ASTM A519 1035 Seamless Carbon and Alloy Steel Mechanical Tubing For Hydraulic Application
Material, Specification, Key Features
ASTM A519 1035 Seamless Carbon and Alloy Steel Mechanical Tubing is specified by the American Society for Testing and Materials (ASTM) for hydraulic applications. This type of tubing is known for its seamless construction, combining carbon and alloy steel for enhanced mechanical properties. The key features of ASTM A519 1035 include high strength, durability, and suitability for hydraulic machinery.
Chemical Composition
| Element | Percentage (%) |
|---|---|
| Carbon | 0.32-0.38 |
| Manganese | 0.60-0.90 |
| Phosphorus | 0.040 max |
| Sulfur | 0.050 max |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 580 MPa |
| Yield Strength | 385 MPa |
| Elongation | 18% |
| Hardness Rockwell B | 84 |
Steel Grade
ASTM A519 1035 falls under the category of carbon and alloy steel materials with a focus on structural applications, particularly in hydraulic systems. It is well-suited for environments requiring high strength and toughness while maintaining formability and weldability.
Application
This type of tubing is commonly employed in hydraulic systems, where the combination of strength and ductility is crucial for withstanding high pressure and dynamic forces. Its seamless construction ensures reliable performance in demanding environments, making it ideal for hydraulic applications that require precision and reliability.
Possible Alternative Grades
In situations where ASTM A519 1035 may not be readily available or for specific application requirements, potential alternative grades that can be considered include ASTM A519 4130, ASTM A519 1026, and ASTM A519 1045. These alternatives offer similar mechanical properties and characteristics suitable for various mechanical and hydraulic applications.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
