GB/T 3077 38CrMoAL Cold Drawn Carton Seamless Alloy Steel Pipe For Automobile Industry
Material
The material used in the manufacturing of this seamless alloy steel pipe is 38CrMoAL as per the GB/T 3077 standard.
Specification
- Standard: GB/T 3077
- Grade: 38CrMoAL
- Production method: Cold drawn
- Application: Automobile Industry
Key Features
- Seamless construction
- High strength and durability
- Suitable for automotive applications
- Cold drawn for improved dimensional accuracy
- Resistant to wear and tear
Chemical Composition
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.35 - 0.42 |
| Silicon (Si) | 0.20 - 0.50 |
| Manganese (Mn) | 0.30 - 0.60 |
| Phosphorus (P) | ≤ 0.030 |
| Sulfur (S) | ≤ 0.030 |
| Chromium (Cr) | 0.70 - 1.10 |
| Molybdenum (Mo) | 0.15 - 0.25 |
| Aluminum (Al) | 0.70 - 1.10 |
Mechanical Properties
| Property | Value |
|---|---|
| Tensile Strength | 700 - 850 MPa |
| Yield Strength | 450 MPa min |
| Elongation | ≥13% |
| Hardness | 250 HB max |
Steel Grade
The steel grade for this alloy steel pipe is 38CrMoAL as per GB/T 3077 standard.
Application
This cold drawn seamless alloy steel pipe is specifically designed for use in the automobile industry due to its high strength, durability, and wear resistance properties.
Possible Alternative Grades
- 40Cr
- 42CrMo
- 35CrMo
This comprehensive article outlines the key details of GB/T 3077 38CrMoAL Cold Drawn Seamless Alloy Steel Pipe, including its material composition, specifications, key features, chemical composition, mechanical properties, steel grade, application in the automobile industry, and potential alternative grades.
