JIS G3454 SCM415 JIS Cold Drawn Carbon Steel Seamless Steel Pipe For Pressure Service
Product Details
Carbon Seamless Steel Pipe
,SCM415 Seamless Steel Pipe
,Pressure Seamless Steel Pipe
JIS G3454 SCM415 JIS Cold Drawn Carbon Steel Seamless Steel Pipe For Pressure Service
Material
The JIS G3454 SCM415 is a cold-drawn carbon steel seamless steel pipe designed for pressure service applications.
Specification
- Standard: JIS G3454
- Material: SCM415
- Type: Cold-drawn Carbon Steel Seamless Pipe
- Application: Pressure Service
Key Features
- Designed for high-pressure applications
- Cold-drawn manufacturing process ensures enhanced strength and durability
- Precise dimensional accuracy for seamless integration
Chemical Composition
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.13-0.18 |
| Silicon (Si) | 0.15-0.35 |
| Manganese (Mn) | 0.60-0.85 |
| Phosphorus (P) | 0.030 max |
| Sulfur (S) | 0.030 max |
| Chromium (Cr) | 0.90-1.20 |
| Molybdenum (Mo) | 0.15-0.30 |
Mechanical Properties
| Properties | Values |
|---|---|
| Tensile Strength | 600-800 MPa |
| Yield Strength | 450 MPa min |
| Elongation | 18% min |
| Hardness (HB) | 160-190 HB |
Steel Grade
The steel grade SCM415 falls under the JIS G3454 standard and is known for its application in pressure service due to its robust mechanical properties.
Application
This cold-drawn carbon steel seamless steel pipe, SCM415, is widely used in industries requiring high-pressure piping systems such as boiler and heat exchanger, power plants, and refineries.
Possible Alternative Grades
For applications where SCM415 might not be readily available or suitable, alternative grades such as SCM430 or SCM435 can be considered, depending on specific requirements and availability.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
