ASTM A789 Super Duplex 2507 Pipe Cold Drawn Stainless Steel Tube For Petrochemical
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 1Ton | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | In bundles or in wooden boxes. | Delivery Time : | 20-40days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 60000 Ton/Tons per Year |
| Place of Origin: | ZheJiang/China | Brand Name: | TORICH |
|---|---|---|---|
| Model Number: | GB 30813 |
|
Detail Information |
|||
| Certification: | ISO9001-2008 | Application: | Nuclear Power Plant |
|---|---|---|---|
| Standard: | GB | Technique: | Cold Drawn,Hot Rolled,Cold Rolled,ERW |
| Surface Treatment: | Customerized | Grade: | 06Cr19Ni10; 022Cr19Ni10; 022Cr19Ni10N; 06Cr18Ni11Ti; 06Cr17Ni12Mo2; 022Cr17Ni12Mo2; 022Cr17Ni12Mo2N |
| Alloy Or Not: | Non-alloy | Section Shape: | Round,Rectangular |
| Special Pipe: | Precision Steel Tube | Secondary Or Not: | Non-secondary |
| Length: | As Customer's Require | Product Name: | Stainless Steel Seamless Pipe 304 304l 316 316l |
| Type: | Welded Or Seamless Tube | Steel Grade: | 300 Series,200series 300series |
| Material: | Steel | ||
| High Light: | Austenitic Stainless Steel Tubes,Nuclear Power Plant Stainless Steel Pipe,Precision Welded Stainless Steel Tubes |
||
Product Description
The GB 30813 standard pertains to welded austenitic stainless steel tubes and pipes specifically designed for use in nuclear power plants. These tubes and pipes play a critical role in ensuring the safe and efficient operation of nuclear power plants. This article will provide an overview of the material, specifications, chemical composition, mechanical properties, and applications of GB 30813 stainless steel tubes and pipes.
The GB 30813 standard specifies the use of austenitic stainless steel for the production of tubes and pipes. Austenitic stainless steel is known for its excellent corrosion resistance, high strength, and durability. These qualities are highly desirable in the harsh and demanding environments found in nuclear power plants. The use of austenitic stainless steel ensures the longevity and reliability of the tubes and pipes, contributing to the overall safety and efficiency of the nuclear power plant.
The GB 30813 standard provides detailed specifications for the production and quality control of austenitic stainless steel tubes and pipes. It covers various aspects, including dimensions, tolerances, surface conditions, and testing requirements. The specifications ensure that the tubes and pipes adhere to strict quality standards and meet the necessary criteria for their intended use in nuclear power plants.
The following table presents the chemical composition requirements specified in GB 30813 for the austenitic stainless steel used in the production of tubes and pipes for nuclear power plants:
| Element | Chemical Composition (%) |
|---|---|
| Carbon (C) | ≤ 0.035 |
| Silicon (Si) | ≤ 1.00 |
| Manganese (Mn) | ≤ 2.00 |
| Phosphorus (P) | ≤ 0.040 |
| Sulfur (S) | ≤ 0.030 |
| Nickel (Ni) | 9.0 - 12.0 |
| Chromium (Cr) | 17.0 - 20.0 |
| Molybdenum (Mo) | ≤ 0.65 |
| Nitrogen (N) | ≤ 0.10 |
Note: These values are for reference only and should be verified with the updated GB 30813 standard.
The mechanical properties of the austenitic stainless steel tubes and pipes conforming to GB 30813 are as follows:
| Property | Minimum Value |
|---|---|
| Tensile Strength (MPa) | ≥ 520 |
| Yield Strength (MPa) | ≥ 205 |
| Elongation (%) | ≥ 35 |
| Hardness (HRB) | ≤ 90 |
| Impact Toughness (J/cm²) | ≥ 50 |
Note: These values are for reference only and should be verified with the updated GB 30813 standard.
GB 30813 welded Austenitic Stainless Steel Tubes and Pipes find their application in nuclear power plants for various purposes, including:
Coolant Circulation: These tubes and pipes are used to circulate coolant within the nuclear power plant to remove excess heat generated during the power generation process.
Steam Generation: Austenitic stainless steel tubes and pipes are utilized to generate steam in the nuclear power plant, which drives the turbines and generates electricity.
Containment Systems: These tubes and pipes are also employed in the construction of containment systems that ensure the safe confinement of radioactive materials within the power plant.
The high-quality and durable nature of GB 30813 welded Austenitic Stainless Steel Tubes and Pipes make them the ideal choice for critical applications in nuclear power plants.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
