GB/T 21833 Austenitic Ferritic Duplex Grade Stainless Steel Seamless Tubes And Pipes For General Purpose
Introduction
GB/T 21833 is the Chinese national standard that specifies the requirements for austenitic ferritic duplex grade stainless steel seamless tubes and pipes for general-purpose applications. This standard ensures that the material meets specific quality and performance criteria. This article provides essential information about the material, its specifications, key features, chemical composition, mechanical properties, steel grade, application, and possible alternative grades.
Material
The material covered by GB/T 21833 is austenitic ferritic duplex grade stainless steel. This type of stainless steel combines the characteristics of both austenitic and ferritic stainless steels, offering exceptional corrosion resistance and high strength. It possesses good weldability and formability, making it suitable for various applications.
Specification
GB/T 21833 specifies the requirements for seamless tubes and pipes made from austenitic ferritic duplex grade stainless steel. The standard covers dimensions, tolerances, testing methods, and other technical specifications necessary for ensuring the quality and reliability of the material.
Key Features
Austenitic ferritic duplex grade stainless steel seamless tubes and pipes possess several key features, including:
- Corrosion Resistance: These tubes and pipes exhibit excellent resistance to corrosion, particularly in aggressive environments such as seawater, acidic solutions, and chloride-containing environments.
- High Strength: Duplex stainless steel offers superior strength compared to austenitic stainless steels, making it suitable for applications requiring structural integrity.
- Good Weldability: The material is readily weldable, allowing for easy fabrication and installation.
- Formability: Duplex stainless steel can be formed into various shapes without compromising its corrosion resistance and mechanical properties.
- Fatigue Resistance: These tubes and pipes exhibit high resistance to fatigue and stress corrosion cracking.
Chemical Composition
| Element | Minimum (%) | Maximum (%) |
|---|---|---|
| Chromium (Cr) | 18.0 | 23.0 |
| Nickel (Ni) | 3.0 | 8.0 |
| Molybdenum (Mo) | 0.10 | 3.0 |
| Nitrogen (N) | 0.10 | 0.30 |
| Manganese (Mn) | - | 2.0 |
| Silicon (Si) | - | 1.0 |
| Copper (Cu) | - | 1.0 |
| Phosphorus (P) | - | 0.035 |
| Sulfur (S) | - | 0.015 |
Mechanical Properties
| Property | Minimum Value | Maximum Value |
|---|---|---|
| Tensile Strength (MPa) | 620 | 880 |
| Yield Strength (MPa) | 450 | 640 |
| Elongation (%) | 25 | 35 |
| Hardness (HB) | - | 290 |
Steel Grade
GB/T 21833 provides several steel grades for austenitic ferritic duplex stainless steel seamless tubes and pipes, including:
- 00Cr22Ni5Mo3N
- 00Cr25Ni7Mo4N
- 00Cr25Ni6Mo3CuN
- 00Cr25Ni7Mo4WCuN
Application
Austenitic ferritic duplex grade stainless steel seamless tubes and pipes specified by GB/T 21833 find widespread application in various industries. Some common usage areas include:
- Oil and Gas: These tubes and pipes are used in offshore platforms, subsea pipelines, and processing facilities due to their excellent corrosion resistance in harsh environments.
- Chemical Processing: Duplex stainless steel is ideal for applications involving corrosive chemicals, such as chemical reactors, heat exchangers, and storage tanks.
- Desalination: The material's resistance to chloride-induced corrosion makes it suitable for desalination plants and equipment.
- Pulp and Paper: Duplex stainless steel is used in the production of paper and pulp, where it withstands the corrosive nature of chemicals and fluids used in the process.
- Construction: Its high strength and corrosion resistance make it an excellent choice for structural components in buildings, bridges, and other infrastructure.
Possible Alternative Grades
While GB/T 21833 specifies specific grades, there are alternative stainless steel grades available for similar applications. Some possible alternative grades to austenitic ferritic duplex stainless steel include:
- Austenitic Stainless Steel: Such as AISI 316, AISI 304, or ASTM A240.
- Ferritic Stainless Steel: Examples include AISI 430, AISI 446, or ASTM A268.
- Super Duplex Stainless Steel: Grades like 2507 or ASTM A789.
It's important to consider specific requirements and consult with material experts when selecting alternative grades for particular applications.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
