ASTM A519 1035 Seamless Carbon And Alloy Steel Mechanical Tubing For Hydraulic
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 1Ton | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | In bundles or in wooden boxes. | Delivery Time : | 20-40days |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 60000 Ton/Tons per Year |
| Place of Origin: | ZheJiang/China | Brand Name: | TORICH |
|---|---|---|---|
| Model Number: | DIN 17175 16Mo5 |
|
Detail Information |
|||
| Certification: | ISO | Standard2: | DIN 17175 |
|---|---|---|---|
| Thickness: | 1 - 8 Mm | Standard: | DIN |
| Grade: | 16Mn | Grade Group: | 16Mn |
| Application: | Boiler | Section Shape: | Round |
| Alloy Or Not: | Non-alloy | Technique: | Hot Rolled,Cold Rolled |
| Surface Treatment: | Customerized | Secondary Or Not: | Non-secondary |
| Special Pipe: | Precision Seamless Pipe | Usage: | Construction Structure |
| Shape: | Round Shape | Product Name: | Seamless Steel Tube |
| Surface: | Customers't Requirement | ||
| High Light: | Hot Rolled Seamless Boiler Tube,Seamless Steel Pipe Heat Resistant,16Mo5 Seamless Steel Pipe |
||
Product Description
The DIN 17175 16Mo5 hot rolled heat-resistant seamless steel pipe is a high-quality pipe specifically designed for boiler applications. With its exceptional heat resistance and seamless construction, it is a reliable choice for various industrial heating processes. This article will delve into the material, specifications, key features, chemical composition, mechanical properties, steel grade, application, and possible alternative grades of this steel pipe.
The DIN 17175 16Mo5 hot rolled heat-resistant seamless steel pipe is manufactured using high-quality raw materials and adheres to the specifications set by the DIN 17175 standard. The pipe is specifically designed to withstand high temperatures and pressure conditions encountered in boiler applications. Its seamless construction ensures excellent durability and structural integrity.
The key features of DIN 17175 16Mo5 hot rolled heat-resistant seamless steel pipe include:
Heat resistance: The pipe exhibits exceptional resistance to high temperatures, making it suitable for boiler applications.
Seamless construction: With its seamless design, the pipe ensures improved reliability and reduces the risk of leaks or failure under extreme conditions.
Durability: The high-quality materials and precise manufacturing techniques used in the production of this steel pipe contribute to its exceptional strength and longevity.
Corrosion resistance: The pipe is highly resistant to corrosion, ensuring a longer service life and reducing maintenance requirements.
Wide application: The pipe's versatile nature allows it to be used in various industrial heating processes beyond boiler applications.
The chemical composition of DIN 17175 16Mo5 hot rolled heat-resistant seamless steel pipe is as follows:
| Element | Composition (%) |
|---|---|
| C | 0.12-0.20 |
| Si | 0.10-0.35 |
| Mn | 0.40-0.90 |
| P | ≤0.025 |
| S | ≤0.020 |
| Cr | 0.70-1.15 |
| Mo | 0.25-0.35 |
The mechanical properties of DIN 17175 16Mo5 hot rolled heat-resistant seamless steel pipe are as follows:
| Property | Value |
|---|---|
| Tensile strength | 440-590 MPa |
| Yield strength | ≥ 290 MPa |
| Elongation | 22% (longitudinal) |
| Impact energy | ≥27 J (longitudinal) |
| Hardness | ≤ 255 HB (up to 100mm) |
The steel grade 16Mo5 corresponds to the European standard EN 10028-2 and is widely used in the boiler industry. It offers excellent heat resistance and meets the high standards required for boiler applications.
The DIN 17175 16Mo5 hot rolled heat-resistant seamless steel pipe is primarily used in boiler applications. Its heat resistance and exceptional mechanical properties make it suitable for carrying steam, high-temperature fluids, and gases in industrial settings. Additionally, its corrosion resistance and durable construction ensure reliable performance in demanding environments.
There are several possible alternative grades to DIN 17175 16Mo5 depending on specific requirements and applications. Some commonly considered alternatives include:
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
