YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well

Minimum Order Quantity : 1Ton Price : Negotiable
Packaging Details : In bundles or in wooden boxes. Delivery Time : 20-40days
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram Supply Ability : 60000 Ton/Tons per Year
Place of Origin: ZheJiang/China Brand Name: TORICH
Certification: ISO9001 ISO14001 TS16949 Model Number: YB/T 4028

Detail Information

Section Shape: Round Secondary Or Not: Non-secondary
Technique: ERW EFW Application: Water Pump Of Deep Well
Surface Treatment: Galvanized Alloy Or Not: Non-alloy
Standard: GB Grade: Q235,Q345,Q195
Standard2: YB/T 4028 Grade Group: Q195-Q345
Special Pipe: Precision Tube Surface: Galvanized Coated
Material: Q195/Q215/Q235/Q345 Product Name: Galvanized Round Pipe
Highlight:

Electric Welding Galvanized Tube

,

Galvanized Welded Steel Tube

,

Straight Seam Welded Steel Tube

Product Description

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 0

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well

Table of Contents

  1. Material
  2. Specification
  3. Key Features
  4. Chemical Composition
  5. Mechanical Properties
  6. Steel Grade
  7. Application
  8. Possible Alternative Grades

Material

Material Type Welded Steel
Surface Treatment Galvanized
Manufacturing Process Electric Welding
Application Water Pump of Deep Well

Specification

Diameter Range (mm) 21.3 - 219.1
Wall Thickness (mm) 1.6 - 7.0
Length (m) Customizable
Standard YB/T 4028
Available Grades Q195, Q215, Q235

Key Features

  • Suitable for use in deep well water pumps.
  • High-quality welded steel construction.
  • Corrosion-resistant galvanized surface.
  • Versatile size range for various applications.

Chemical Composition

Element C (%) Mn (%) Si (%) P (%) S (%)
Composition 0.12 0.30 0.30 0.045 0.045

Mechanical Properties

Property Tensile Strength (MPa) Yield Strength (MPa) Elongation (%)
Mechanical Properties (Q195) 315-430 195 33
Mechanical Properties (Q215) 335-450 215 27
Mechanical Properties (Q235) 375-500 235 25

Steel Grade

  • Q195: A low-carbon steel grade with good ductility and weldability, suitable for various applications.
  • Q215: A medium-carbon steel grade with improved strength, often used for structural purposes.
  • Q235: A high-strength steel grade, suitable for load-bearing applications.

Application

The YB/T 4028 Welded Steel Tube with straight seam electric welding and a galvanized surface is specifically designed for use in water pumps for deep wells. Its reliable construction and corrosion-resistant properties make it an ideal choice for this demanding application.


Possible Alternative Grades

If the specified grade is not available or other requirements are needed, you may consider alternative steel grades such as:

  • Q195: Suitable for general applications with lower strength requirements.
  • Q215: Offers improved strength compared to Q195 and is often used for structural purposes.
  • Q235: Provides higher strength and is ideal for load-bearing components.

These alternative grades offer flexibility to meet specific project needs and budget constraints.



YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 1



YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 2    YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 3

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 4    YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 5

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 6







YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 7

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 8

Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.

Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.

At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 9

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 10

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 11

YB/T 4028 Welded Steel Tube Straight Seam Electric Welding Galvanized Tube For Water Pump Of Deep Well 12



Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.



Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
