GB/T 17396 Hot Rolled Steel Hydraulic Tubing Seamless Steel Tubes For Hydraulic Pillar Service
Product Details
GB/T 17396 Steel Hydraulic Tubing
,Hydraulic Pillar Service Seamless Steel Tubes
,Hydraulic Hot Rolled Seamless Steel Tubes
GB/T 17396 Hot Rolled Steel Hydraulic Tubing Seamless Steel Tubes For Hydraulic Pillar Service
Material
The material used in GB/T 17396 Hot Rolled Steel Hydraulic Tubing is high-quality carbon structural steel.
Specification
The specification for GB/T 17396 Hot Rolled Steel Hydraulic Tubing is as follows:
- Outer diameter: 4-76mm
- Wall thickness: 0.5-13mm
Chemical Composition
The chemical composition of GB/T 17396 Hot Rolled Steel Hydraulic Tubing is as follows:
| Element | Chemical Composition (%) |
|---|---|
| C | 0.17-0.24 |
| Si | 0.17-0.37 |
| Mn | 0.50-0.80 |
| P | ≤0.035 |
| S | ≤0.035 |
Mechanical Properties
The mechanical properties of GB/T 17396 Hot Rolled Steel Hydraulic Tubing are as follows:
| Property | Value |
|---|---|
| Yield Strength (MPa) | ≥345 |
| Tensile Strength (MPa) | 490-665 |
| Elongation (%) | ≥18 |
| Hardness (HB) | ≤187 |
Steel Grade
The steel grade for GB/T 17396 Hot Rolled Steel Hydraulic Tubing is Q345B.
Application
The GB/T 17396 Hot Rolled Steel Hydraulic Tubing is used for hydraulic pillar service in various industries such as machinery, construction, and transportation. It is specifically designed for applications that require high strength and resistance to external pressure. The seamless steel tubes provide excellent performance and reliability in hydraulic systems.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
