Seamless Carbon Steel Tube ASTM A556 Cold Drawn Steel Tube For Heat Exchanger
Product Details
Cold Drawn Carbon Steel Seamless Tube
,Seamless Steel Tube ASTM A556
,Heat Exchanger Seamless Precision Steel Tube
Seamless Steel Tube Carbon Steel ASTM A556 Cold Drawn Steel Tube For Heat Exchanger
Material
The material used for the seamless steel tube, specifically designed for heat exchangers, is carbon steel. This type of steel is known for its excellent strength and durability, making it suitable for high-pressure and high-temperature applications.
Specification
The seamless steel tube is manufactured according to the ASTM A556 standard. This specification provides guidelines for the production of seamless cold-drawn carbon steel tubes for use in heat exchangers. It ensures the tubes meet the necessary requirements for chemical composition, mechanical properties, and dimensional accuracy.
Chemical Composition
The chemical composition of the seamless steel tube is as follows:
| Element | Composition (%) |
| Carbon | 0.17 max |
| Manganese | 0.37-0.64 |
| Phosphorus | 0.035 max |
| Sulfur | 0.035 max |
| Silicon | 0.10-0.35 |
Mechanical Properties
The seamless steel tube exhibits excellent mechanical properties, allowing it to withstand the demanding conditions of heat exchangers. The following table outlines the typical mechanical properties of ASTM A556 carbon steel tubes:
| Property | Value |
| Tensile Strength | 325 MPa min |
| Yield Strength | 180 MPa min |
| Elongation | 35% min |
| Hardness | HRB 80-90 |
Physical Properties
In addition to its chemical and mechanical properties, the seamless steel tube possesses certain physical characteristics. These properties include:
| Property | Value |
| Density | 7.85 g/cm³ |
| Melting Point | 1420-1460°C |
| Thermal Conductivity | 51.9 W/m·K |
| Electrical Conductivity | 1.45 MS/m |
| Modulus of Elasticity | 200 GPa |
Process Performance
The seamless steel tube is produced using a cold-drawn process, which involves pulling the tube through a die to achieve the desired dimensions. This manufacturing technique ensures the tube's excellent surface finish, dimensional accuracy, and enhanced mechanical properties. The cold-drawn process also enhances the tube's resistance to corrosion and provides better tolerance control.
Application
The ASTM A556 seamless steel tube is specifically designed for use in heat exchangers. Heat exchangers are widely used in various industries, including power generation, chemical processing, oil and gas, and HVAC systems. The seamless carbon steel tube's high strength and resistance to high temperatures make it ideal for transferring heat between two fluids while maintaining structural integrity.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
