16MnCr6 20MnCr5 20CrMn Alloy Steel Pipe , Cold Drawn Seamless Steel Tube TS16949
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO 9001:2008 , TS16949
Model Number:
20MnCr5 , 20CrMn
Trading Properties
Minimum Order Quantity:
5MT
Price:
negotiable
Payment Terms:
L/C, T/T
Supply Ability:
6000MT/Month
Product Summary
Alloy Steel Tubes and Pipes 16MnCr5 20MnCr5 20CrMn Alloy steel grade 20MnCr5 equivalent to 20CrMn Steel Tubes with alloy steel grade 20MnCr5: 16MnCr5 C:0.14-0.19, Mn:1.00-1.30, P≤0.035, S≤0.010-0.050, Cr:0.80-1.10, Si≤0.40 20MnCr5 C:0.17-0.22, Mn:1.10-1.50, P≤0.035, S≤0.10-0.050, Cr:1.00-1.30, Si≤0...
Product Details
Highlight:
alloy steel seamless tube
,seamless alloy steel pipe
Material:
Alloy Steel
Grade:
20MnCr5 20CrMn
Production:
Cold Drawn Or Hot Finish
Type:
Seamless
Product Description
Alloy Steel Tubes and Pipes 16MnCr5 20MnCr5 20CrMn
Alloy steel grade 20MnCr5 equivalent to 20CrMn
Steel Tubes with alloy steel grade 20MnCr5:
16MnCr5
C:0.14-0.19,
Mn:1.00-1.30,
P≤0.035,
S≤0.010-0.050,
Cr:0.80-1.10,
Si≤0.40
20MnCr5
C:0.17-0.22,
Mn:1.10-1.50,
P≤0.035,
S≤0.10-0.050,
Cr:1.00-1.30,
Si≤0.25
20CrMn
C:0.17-0.23,
Mn: 0.90-1.20,
Cr:1.00-1.30,
Si:0.17-0.37
Mechanical Properties:
Tensile strength: min 885Mpa
Yield strength: min 685Mpa
Elongation: min 12%
Hardness: max 190HB
C:0.14-0.19,
Mn:1.00-1.30,
P≤0.035,
S≤0.010-0.050,
Cr:0.80-1.10,
Si≤0.40
20MnCr5
C:0.17-0.22,
Mn:1.10-1.50,
P≤0.035,
S≤0.10-0.050,
Cr:1.00-1.30,
Si≤0.25
20CrMn
C:0.17-0.23,
Mn: 0.90-1.20,
Cr:1.00-1.30,
Si:0.17-0.37
Mechanical Properties:
Tensile strength: min 885Mpa
Yield strength: min 685Mpa
Elongation: min 12%
Hardness: max 190HB
Precision Steel Pipes 16MnCr5 20MnCr5 20CrMn Container Loading:
