ASTM A179 U Bend Tubes Low Carbon Heat Exchanger Seamless Steel Tubes
Basic Properties
Place of Origin:
China
Brand Name:
TORICH
Certification:
ISO9001:2008, ISO14001, CE PED, TS16949
Model Number:
ASTM A179 ASME A179
Trading Properties
Minimum Order Quantity:
5 TONS
Price:
800-1500 USD/ton
Supply Ability:
20000 tons/year
Product Summary
ASTM A179 Seamless Cold Drawn Low Carbon Steel Heat Exchanger Tubes and Condenser Tubes Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger Tubes and Condenser Tubes Applications: For Boilers, Superheaters, Heat-Exchangers, Condensers U bend Tubes according to Customer request Size range: O.D.:6...
Product Details
Highlight:
bend steel tubing
,bending steel tubing
Standard:
ASTM A179 ASME A179
Material:
Carbon Steel
Type:
U Bending
Production:
Cold Drawn
Application:
Heat Exchangers,Cold Condensors
Dimension:
OD 15.88-114mm
Product Description
ASTM A179 Seamless Cold Drawn Low Carbon Steel Heat Exchanger Tubes and Condenser Tubes
Seamless Cold-Drawn Low-Carbon Steel Heat-Exchanger Tubes and Condenser Tubes
Applications:
- For Boilers,
- Superheaters,
- Heat-Exchangers,
- Condensers
U bend Tubes according to Customer request
Size range: O.D.:6-168mm W.T.:1-15mm L: according to customer requirement.
Steel Grade and Chemical Compositions:
| C | 0.06-0.18 | |
| Mn | 0.27-0.63 | |
| P | ≤0.035 | |
| S | ≤0.035 |
Mechanical Properties
Tensil Streghth: min ksi[Mpa] 47[325]
Yield Point: min ksi[Mpa] 26[180]
Elongation: ≥35%
Hardness: ≤72HRB
