Precision Steel Tubes GOST9567 10 20 35 45 40X 30ХГСА Alloy Steel Tubes
Basic Properties
Place of Origin:
China
Brand Name:
TORICH
Certification:
ISO 9001 ISO 14001 EN 10204.3.1 TS 16949
Model Number:
GOST9567
Trading Properties
Minimum Order Quantity:
5 tons
Price:
USD 600-1200 ton
Supply Ability:
60000tons per year
Product Summary
GOST9567 10 20 35 45 40X 30ХГСА Steel Tubes-Precision Steel Tubes GOST9567 Precision steel tubes TORICH is specialized in manufacturing cold drawn precision steel tube according to technical standard of GOST9567. precision carbon steel tube is usually manufactured from round billet to hollow tubes, ...
Product Details
Highlight:
precision steel pipe
,precision pipes and tubes
Material:
Carbon Steel And Alloy Steel
Steel Grade:
10 20 35 45 40X
Standard:
GOST9567
Shape:
Round
Applications:
Automobile, Machinery Engineering, Autoparts Etc.
Size Range:
O.D.:6-168mm W.T.:1-15mm L:max12000mm
Production Method:
Seamless Cold Drawn
Product Description
GOST9567 10 20 35 45 40X 30ХГСА Steel Tubes-Precision Steel Tubes
GOST9567 Precision steel tubes
TORICH is specialized in manufacturing cold drawn precision steel tube according to technical standard of GOST9567.
precision carbon steel tube is usually manufactured from round billet to hollow tubes, then after several cold drawn process to the final diemenion with target size tolerances and mechanical properties.
Applications of carbon steel precision tube:
Automobile, Machinery Engineering, Autoparts etc.
Size range of cold-drawn precision seamless steel tube:
O.D.:6-168mm W.T.:1-15mm L:max12000mm
Chemical Composition(%,max) for carbon steel precision tube:
| Steel Grade | C | Si | Mn | Cr | Ni | Mo | S | P | Cu |
| 10 | 0.07-0.14 | 0.17-0.37 | 0.35-0.65 | 0.15 | 0.3 | - | - | - | - |
| 20 | 0.17-0.24 | 0.17-0.37 | 0.35-0.65 | 0.25 | 0.25 | - | 0.03 | 0.025 | 0.3 |
| 35 | 0.32-0.40 | 0.17-0.37 | 0.50-0.80 | 0.25 | 0.3 | - | 0.04 | 0.035 | 0.3 |
| 45 | 0.42--0.45 | 0.17-0.37 | 0.50-0.80 | 0.25 | - | - | - | - | - |
| 40X | 0.36-0.44 | 0.17-0.37 | 0.50-0.80 | 0.80-1.10 | 0.3 | - | 0.035 | 0.035 | 0.3 |
| 30ХГСА | 0.28-0.34 | 0.90-1.20 | 0.80-1.10 | 0.80-1.10 | 0.3 | - | 0.005 | 0.025 | - |
Mechanical Properties:
| Steel Grade | Tensile Strength, N/mm2 (min) | Yield Strength, N/mm 2 (min) | Elongation, %(min) |
| 10 | 343 | 206 | 24 |
| 20 | 412 | 245 | 21 |
| 35 | 510 | 294 | 17 |
| 45 | 589 | 323 | 14 |
| 40X | 618 | - | 14 |
| 30ХГСА | 491 | - | 18 |
Production and Quality Inspection:
