Astm A209 T1 Alloy Seamless Steel Tube For Boiler And Superheater
Product Details
astma209 t1 alloy seamless steel tube
,boiler alloy seamless steel tube
,superheater alloy seamless steel pipe
Alloy Seamless Steel Tube Pipe ASTM A209 T1 For Boiler And Superheater
Material
The material used for the Alloy Seamless Steel Tube Pipe ASTM A209 T1 is a low alloy steel that offers excellent strength and durability. It is specifically designed for high-temperature applications in boilers and superheaters. The composition of the material ensures its ability to withstand elevated temperatures and pressures while maintaining structural integrity.
Specification
The Alloy Seamless Steel Tube Pipe ASTM A209 T1 follows specific specifications to meet the requirements of boiler and superheater applications. The specifications include:
- Outer Diameter: Range from 6mm to 350mm
- Wall Thickness: Range from 0.8mm to 35mm
- Length: Maximum 25 meters
- Tolerance: According to ASTM A209 standard
Chemical Composition
The chemical composition of Alloy Seamless Steel Tube Pipe ASTM A209 T1 is carefully controlled to ensure its suitability for boiler and superheater applications. The following table presents the chemical composition of this alloy:
| Element | Composition (%) |
|---|---|
| Carbon (C) | 0.10-0.20 |
| Manganese (Mn) | 0.30-0.80 |
| Phosphorus (P) | 0.025 max |
| Sulfur (S) | 0.025 max |
| Silicon (Si) | 0.10-0.50 |
| Chromium (Cr) | 0.44-0.65 |
| Molybdenum (Mo) | 0.45-0.65 |
Mechanical Properties
The Alloy Seamless Steel Tube Pipe ASTM A209 T1 exhibits excellent mechanical properties, which are essential for its performance under high-temperature and high-pressure conditions. The following table highlights the mechanical properties of this alloy:
| Property | Value |
|---|---|
| Tensile Strength | 415-585 MPa |
| Yield Strength | 220 MPa (min) |
| Elongation | 30% (min) |
| Hardness | 163-255 HBW |
| Impact Toughness | 27 J (min) |
Steel Grade
The steel grade of Alloy Seamless Steel Tube Pipe ASTM A209 T1 is specifically designated as T1. This grade signifies its unique composition and mechanical properties tailored for boiler and superheater applications. T1 steel offers exceptional resistance to high temperatures and provides long-lasting performance under demanding conditions.
Application
The Alloy Seamless Steel Tube Pipe ASTM A209 T1 is widely used in various industrial applications, primarily in boilers and superheaters. It is specifically designed to withstand high temperatures and pressures, making it suitable for power generation, petrochemical, and refinery industries. The seamless construction of the tube pipe ensures efficient heat transfer, while the alloy composition enhances its strength and durability.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
Q: Are you trading company or manufacturer ?
A: manufacturer,also can do trading.
Q: How long is your delivery time?
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
Q: Do you provide samples? is it free or extra ?
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
-
