Customized GOST 9567-75 Cold Drawn Structural Carbon Seamless Pipe For Pipeline Transport
Contact Person : Richard SHEN
Phone Number : +86-13736164628
WhatsApp : +8613736164628
| Minimum Order Quantity : | 1Tons | Price : | Negotiable |
|---|---|---|---|
| Packaging Details : | in bundles or in wooden box | Delivery Time : | 4-8weeks |
| Payment Terms : | L/C, D/A, D/P, T/T, Western Union, MoneyGram | Supply Ability : | 5000Tons per Year |
| Place of Origin: | China,zhejiang | Brand Name: | TORICH |
|---|---|---|---|
| Certification: | ISO9001, ISO14001, TS16949 | Model Number: | ASTM A192 |
|
Detail Information |
|||
| Application: | Boiler Pipe | Standard: | ASTM |
|---|---|---|---|
| Thickness: | 2.2-25.4mm | Certification: | ISO,ISO9001-2008 |
| Alloy Or Not: | Is Alloy | Section Shape: | Round |
| Outer Diameter(round): | 12.7-177.8mm | Secondary Or Not: | Non-secondary |
| Product Name: | Cold Drawn Precision Round Carbon Steel Tube | Type: | Welded Or Seamless Tube |
| High Light: | Carbon Steel Pipe ASTM A192,Carbon Steel Pipe 2.2mm,Boiler Seamless Tube |
||
Product Description
The material used for the seamless tube carbon steel pipe conforming to ASTM A192 specification is carbon steel.
The specification of the seamless tube carbon steel pipe ASTM A192 is as follows:
| Specification | Value |
|---|---|
| Standard | ASTM A192 |
| Outer Diameter | As per requirement |
| Wall Thickness | As per requirement |
| Length | As per requirement |
The chemical composition of the seamless tube carbon steel pipe ASTM A192 is as follows:
| Element | Composition Range (%) |
|---|---|
| Carbon (C) | 0.06-0.18 |
| Manganese (Mn) | 0.27-0.63 |
| Phosphorus (P) | 0.035 (Max) |
| Sulfur (S) | 0.035 (Max) |
| Silicon (Si) | 0.25 (Max) |
The mechanical properties of the seamless tube carbon steel pipe ASTM A192 are as follows:
| Property | Minimum Value |
|---|---|
| Tensile Strength | 325 MPa |
| Yield Strength | 180 MPa |
| Elongation | 35% (Min) |
| Hardness | 77 HRB (Max) |
The steel grade of the seamless tube carbon steel pipe ASTM A192 is Grade C.
The seamless tube carbon steel pipe ASTM A192 is specifically designed for high-pressure boilers. It is widely used in power plants, refineries, and other industrial applications where high-pressure and high-temperature conditions are present. This pipe ensures efficient heat transfer and reliable performance in boiler systems.
Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.
Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.
At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.
A: manufacturer,also can do trading.
A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.
A: Yes, we could offer the sample for free charge but need pay the cost of freight.
A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact with me.
