JIS G3456 Seamless Steel Tube For High Temperature Service Carbon Steel Pipes
Product Details
JIS G3456 Seamless Steel Tube
,High Temperature Service Seamless Steel Tube
,Round Seamless Carbon Steel Pipes
Introduction: JIS G3456 seamless steel tube is a carbon steel pipe for high-temperature service. The tubes are manufactured by seamless process and the pipe shall be either hot-finished or cold-finished, as specified. The material used in the manufacture of these pipes is carbon steel, which has several advantages over other materials such as stainless steel or alloy steel. This article will provide detailed information on the material, specification, chemical composition, mechanical properties, steel grade, and application of JIS G3452 seamless steel tube.
Material: The material used in the manufacture of JIS G3456 seamless steel tube is carbon steel. Carbon steel is an alloy of iron and carbon, with small amounts of other elements such as manganese, silicon, sulfur, and phosphorus, added to improve its mechanical properties. Carbon steel is widely used in various industries due to its excellent strength, toughness, and impact resistance.
Specification: The specification of JIS G3456 seamless steel tube is as follows:
Outer diameter: 10.5-660.4mm Wall thickness: 1.7-25mm Length: Random length, fixed length, or customized length up to 12m Ends: Plain end, beveled end, threaded end Surface treatment: Black painting, varnish painting, anti-rust oil, hot galvanized, cold galvanized, 3PE, etc.
Chemical Composition: The chemical composition of JIS G3456 seamless steel tube is shown in the following table:
| Element | Chemical Composition (%) |
|---|---|
| Carbon | 0.22 max |
| Silicon | 0.35 max |
| Manganese | 1.30 max |
| Phosphorus | 0.040 max |
| Sulfur | 0.040 max |
Mechanical Properties: The mechanical properties of JIS G3456 seamless steel tube depend on the grade of steel used. The following table shows the mechanical properties of steel grades STPG370 and STPG410:
| Steel Grade | Yield Strength (MPa) | Tensile Strength (MPa) | Elongation (%) |
|---|---|---|---|
| STPG370 | 215 min | 370 min | 30 min |
| STPG410 | 245 min | 410 min | 25 min |
Steel Grade: There are two grades of steel used in the manufacture of JIS G3456 seamless steel tube: STPG370 and STPG410. These grades have different mechanical properties, but both are suitable for high-temperature service.
Application: JIS G3456 seamless steel tube is widely used in various industries such as petroleum, chemical, power generation, boiler, and machinery manufacturing due to its excellent strength and high-temperature resistance. It is commonly used for transporting fluids and gases at high temperatures and pressures.
