Seamless Cold Drawn Low Carbon Steel Heat Exchanger Condenser Tubes ASTM A179

Minimum Order Quantity : 1Tons Price : Negotiable
Packaging Details : in bundles or in wooden box Delivery Time : 4-8weeks
Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram
Place of Origin: China,zhejiang Brand Name: TORICH
Certification: ISO9001, ISO14001, TS16949 Model Number: ASTM A179

Detail Information

Thickness: 0.5 - 50 Mm Standard: ASTM
Application: Boiler Pipe Section Shape: Round
Alloy Or Not: Is Alloy Technique: Cold Drawn
Secondary Or Not: Non-secondary
High Light:

Low Carbon Steel Condenser Tubes

,

Seamless Cold Drawn Condenser Tubes

,

Heat Exchanger Seamless Steel Tube 0.5mm

Product Description

Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 0

ASTM A179 Seamless Cold Drawn Low Carbon Steel Heat-Exchanger And Condenser Tubes

ASTM A179 is a standard specification for seamless cold drawn low carbon steel heat-exchanger and condenser tubes. This specification covers minimum wall thickness, seamless cold drawn low carbon steel tubes for tubular heat exchangers, condensers, and similar heat transfer apparatus.

Material and Specification

The ASTM A179 specification covers tubes with nominal wall thickness ranging from 0.035 inch to 1.000 inch (0.89mm to 25.4mm) and tube sizes up to 5 inches in diameter (127mm). The tubes shall be made by the seamless process and shall be cold drawn. The steel materials used in the manufacture of these tubes are low carbon steel, with a maximum carbon content of 0.06%.

Chemical Composition

The chemical composition of ASTM A179 steel material is as follows:

Element Composition, %
Carbon 0.06 max
Manganese 0.27 - 0.63
Phosphorus 0.035 max
Sulfur 0.035 max

Mechanical Properties

The mechanical properties of ASTM A179 steel material are as follows:

Property Value
Tensile Strength min. 325 MPa (47,000 psi)
Yield Strength min. 180 MPa (26,000 psi)
Elongation min. 35%

Steel Grade

ASTM A179 defines multiple grades of seamless cold drawn low carbon steel tubes. These grades are as follows:

Steel Grade Chemical Composition
A179/SA179 Carbon: 0.06 max<br>Manganese: 0.27 - 0.63<br>Phosphorus: 0.035 max<br>Sulfur: 0.035 max

Application

ASTM A179 seamless cold drawn low carbon steel tubes are mainly used in the manufacturing of heat exchangers, condensers, and other similar heat transfer equipment. They are suitable for applications where high-pressure, high-temperature, or corrosive conditions are present. These tubes have good heat transfer properties and are widely used in various industrial applications, including chemical processing, power generation, and oil and gas production.



Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 1

Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 2     Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 3



Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 4     Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 5



Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 6







Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 7

Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 8

Haiyan Sanxin Steel Pipe Factory is a leading manufacturer of steel pipes in China. Located in a region with excellent geographical advantages, the factory is situated close to the Zhoushan Port and Ningbo Port.

Our factory covers an area of more than 25,000 square meters and has been in the steel pipe manufacturing business for 20 years. Over this period, we have accumulated a wealth of professional experience, which has helped us establish ourselves as a trusted name in the industry.

At our factory, we specialize in the production of various types of steel pipes, including stainless steel pipe, carbon steel pipe, copper pipe, steel pipe,seamless steel pipe and welded pipe. Our expertise in this field is evident from the 12 patents that we hold, which demonstrate our commitment to innovation and excellence.

Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 9

Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 10

Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 11

Seamless Cold Drawn Low Carbon Steel Heat Exchanger  Condenser Tubes ASTM A179 12



Q: Are you trading company or manufacturer ?

A: manufacturer,also can do trading.



Q: How long is your delivery time?

A: Generally speaking,it is 10-15 days if the goods are in stock,or it is 30-40 days if the goods are not in stock, it is according to quantity.



Q: Do you provide samples? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.



Q: What is your terms of payment ?

A: Payment<=2000USD, 100% in advance. Payment>=2000USD, 30% T/T in advance ,balance before shippment.
