Mechanical Engineer Precision Seamless Steel Tube With Carbon / Alloy

Minimum Order Quantity : 1000 kgs Price : 600-1200
Packaging Details : In bundles with seaworthy packing Delivery Time : 4-6 weeks
Payment Terms : L/C, T/T Supply Ability : 20000 tons per year
Place of Origin: China Brand Name: Torich
Certification: ISO9001:2008, TS16949 Model Number: ASTM A513

Detail Information

High Light:

precision stainless steel tubing

,

seamless carbon steel tube

Product Description

Seamless Carbon and Alloy Steel Mechanical Tubing, are produced according to technica standard of ASTM A519, with steel grade 1010, 1020, 1026, 4130,4140 etc



Size range: O.D.:6-450mm     W.T.:1-30mm      L:max12000mm





                                       Steel Grade and Chemical Compositions:
Steel  C Mn P S Si Cr Mo
Grade max   max max max min
1008 0.10 0.30-0.50 0.040 0.050
1010 0.08-0.13 0.30-0.60 0.040 0.050
1018 0.15-0.20 0.60-0.90 0.040 0.050
1020 0.18-0.23 0.30-0.60 0.040 0.050
1026 0.22-0.28 0.60-0.90 0.040 0.050
1035 0.32-0.38 0.60-0.90 0.040 0.050
1045 0.43-0.50 0.60-0.90 0.040 0.050
4130 0.28-0.33 0.40-0.60 0.040 0.040 0.15-0.35 0.80-1.10 0.15-0.25
4140 0.38-0.43 0.75-1.00 0.040 0.040 0.15-0.35 0.80-1.10 0.15-0.25





Grade condition Ultimat  Yield  Elongation Rockwell
    Strength  Strength   Hardness
    ksi    Mpa ksi    Mpa % B Scale
1020 HR 50     345 32      221 25 55
  CW 70     483 60      414 5 75
  SR 65     448 50      345 10 72
  A 48      331 28      193 30 50
  N 55      379 34      234 22 60
1035 HR 65      448 40      276 20 72
  CW 85      586 75      517 5 88
  SR 75      517 65      448 8 80
  A 60      414 33      228 25 67
  N 65     448 40      276 20 72
1045 HR 75      517 45      310 15 80
  CW 90      621 80      552 5 90
  SR 80      552 70      483 8 85
  A 65      448 35      241 20 72
  N 75     517 48      331 15 80
4130 HR  90       621 70      483 20 89
  SR 105      724 85      586 10 95
  A   75      517 55      379 30 81
  N   90      621 60     414 20 89
4140 HR 120      855 90      310 15 100
  SR 120      855 100    689 10 100
  A   80      552 60      414 25 85
  N 120      855 90      621 20 100





Applications: for machinery, mechanical engineer



Mechanical Engineer Precision Seamless Steel Tube With Carbon / Alloy 0 Mechanical Engineer Precision Seamless Steel Tube With Carbon / Alloy 1



Mechanical Engineer Precision Seamless Steel Tube With Carbon / Alloy 2 Mechanical Engineer Precision Seamless Steel Tube With Carbon / Alloy 3
