Hydraulic Cylinder Precision Welded Steel Pipe ASTM A513 Cold Drawn DOM Tubes

Name: Hydraulic Cylinder Precision Welded Steel Pipe ASTM A513 Cold Drawn DOM Tubes
Brand: TORICH INTERNATIONAL LIMITED
SKU: ASTM A513
Price: 900.00 USD
Availability: InStock

Brand Name:	TORICH
Model Number:	ASTM A513
MOQ:	5TONS
Price:	600-1200 USD/TONS
Supply Ability:	60000 tons one year

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001-2008 ISO 14001 EN 10204.3.1 CCS NK etc

Material:

Carbon Steel

Steel Grade:

SAE1010 SAE1020

Standard:

ASTM A513

Size:

6-350mm*1-15mm*max12000mm

Production Method:

Cold Rolling On The Welded Steel Tubes , To Reach High Accuracy On The OD And WT Tolerance

Delivery Condition:

A.W.H.R / A.W.C.R. / S.D.C.R. / M.D. / S.S.I.D.

Shap:

Round

Applications:

For Machinery, Mechanical Engineering

Packaging Details:

In Hexagonal Bundles, with anti corrosion oil protection, with seaworthy packing

Supply Ability:

60000 tons one year

Highlight:

Precision Cold Drawn Welded Steel Pipe

Hydraulic Cylinder DOM Tubes

ASTM A513 Hydraulic Cylinder Pipe

Product Description

Hydraulic Cylinder Precision Cold Drawn Welded Steel Pipe ASTM A513 DOM Tubes

ASTM A513
Electric-Resistance-Welded Carbon and Alloy Steel Mechanical Tubing
Applications: for Machinery, Mechanical Engineering

1. Standard:
ASTM A513 cold rolling welded precision steel tubes
2. Steel Grade:
SAE1010, SAE1020, other materials upon agreement with customers.

3. Production method:
Cold rolling on the weled steel tubes, to reach high accuracy on the OD and WT tolerance

4. Size range:
O.D.:6-350mm W.T.:1-15mm L:max12000mm

5. Packing:
In Hexagonal Bundles, with anti corrosion oil protection, with seaworthy packing

Delivery condition:

1. A.W.H.R. "as welded" from hot-rolled steel

2. A.W.C.R. "as welded" from cold-rolled steel

3. S.D.C.R. "sink-drawn", cold-rolled steel

5. M.D. mandrel drawn

6. S.S.I.D. special smooth inside diameter

Please specify the delivery condition when sending the enquiry!

Thermal condition:
1. No final thermal treatment
2. Stress relieved
3. Annealed
4. Normalized

Steel Grade and Chemical Compositions:
Steel Grade	C	Mn	P	S	Si	Cr	Mo
Steel Grade	max		max	max	max	min
1008	0.10	0.5	0.035	0.035
1010	0.08-0.13	0.30-0.60	0.035	0.035
1018	0.14-0.20	0.30-0.60	0.035	0.035
1020	0.17-0.23	0.30-0.60	0.035	0.035
1026	0.22-0.28	0.60-0.90	0.035	0.035
1035	0.31-0.38	0.60-0.90	0.035	0.035
4130	0.28-0.33	0.40-0.60	0.035	0.035	0.15-0.35	0.80-1.10	0.08-0.25
4140	0.38-0.43	0.75-1.00	0.035	0.035	0.15-0.35	0.80-1.10	0.15-0.25

Samples for quality checking available:

Application:
Hydraulic Cylinder Precision Welded Steel Pipe ASTM A513 Cold Drawn DOM Tubes 2

Q: Are you trading company or manufacturer ?

A: A professional steel pipes materials inventor, manufacturer and solution provider

Q: How long is your delivery time?

A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, it is according to quantity.

Q: Do you provide samples of stainless steel pipe ? is it free or extra ?

A: Yes, we could offer the sample for free charge but need pay the cost of freight.

Q: What is your terms of payment ?

A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment.
If you have another question, pls feel free to contact us
