ASTM - A524 Seamless Carbon Steel Pipe Atmospheric Lower Temperatures For Auto Parts
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
IS09001 ISO14001 TS16949
Model Number:
ASTM-A524
Trading Properties
Minimum Order Quantity:
1 tons
Price:
negotiable
Payment Terms:
L/C, T/T
Supply Ability:
5000tons per year
Product Summary
ASTM-A524Standard Specification For Seamless Carbon Steel Pipe For Atmospheric And Lower Temperatures For Auto Parts The steel pipe conforms to the American ASTM-A524 standard. It is made of carbon steel pipe billet and produced by European technology. It can effectively control the dimensional ...
Product Details
Highlight:
Atmospheric Carbon Steel Pipe
,A524 Seamless Carbon Steel Pipe
,Lower Temperature Hydraulic Seamless Pipe
Alloy Or Not:
Non-alloy
Technique:
Cold Drawn
Thickness:
0.1 - 10 Mm
Outer Diameter(Round):
4 - 50 Mm
standard2:
ASTM-A524
Special Pipe:
Seamless Tube
Product Name:
ASTM-A524Standard Specification For Seamless Carbon Steel Pipe
Section Shape:
Round
Product Description
ASTM-A524Standard Specification For Seamless Carbon Steel Pipe For Atmospheric And Lower Temperatures For Auto Parts
The steel pipe conforms to the American ASTM-A524 standard. It is made of carbon steel pipe billet and produced by
European technology. It can effectively control the dimensional tolerance of small-diameter thick-walled steel pipe.
The inner and outer diameter tolerance can be controlled within 0.05mm, and the wall thickness tolerance can be
controlled within 0.07mm. Parts with high precision and requirements, auto parts, etc.
Seamless carbon steel tubes as per standard ASTM A524
Chemical composition of ASTM A524
| Element | % |
| C | 0.21 |
| Mn | 0.9-1.35 |
| P | 0.035 max |
| S | 0.035max |
| Si | 0.1-0.4 |
Mechanical properties
| Tensile requirements | Wall thickness | |
| Tensile strength Mpa | Grade I 0.375inch (9.52mm )and under | Grade II,greater than 0.375inch (9.52mm) |
| Yield strength min Mpa | 414-586Mpa | 380-550Mpa
|
| Elongation in 2inch or 50mm | 30 | 25 |
ASTM A524 Grade 1 & 2 (Standard Specification for Seamless Carbon Steel Pipe for Atmospheric and Lower Temperatures)
Size Ranges : 1/8” to 26”
Schedules : 10,20, 30, 40,60, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & heavier
Grades : ASTM A524 Grade 1, ASTM A524 Grade 2
