ASTM A 213 T122 K91271 Seamless Steel Tube High Temperature Boiler Tubes

Basic Information
Place of Origin: China
Brand Name: Torich
Certification: ISO 9001 ISO14001 TS16949
Model Number: ASTM A 213
Minimum Order Quantity: 5 Ton
Price: negotiable
Packaging Details: Packing in wooden, hexagonal box or other seaworthy ways
Delivery Time: 30 days
Payment Terms: T/T L/C D/P D/A WesternUnion MoneyGram Others
Supply Ability: 60000 Ton/Year
Detail Information
Product Name: Seamless Steel Tubes ASTM A 213 T122 K91271 X20CRMOV11-10 38X5 High Temperature Boiler Tubes Material: ASTM A 213 T122 K91271 X20CRMOV11-10
Produce Method: Cold Drawing OD: 76-700mm
WT: 6-50mm Length: 3000-12500mm
Application: Boiler Or Heat Exchanger Type: Seamless
High Light:

High Temperature Boiler Tubes

,

Steel Seamless Boiler Tubes

,

Seamless Steel Pipes K91271


Product Description

Seamless Steel Tubes ASTM A 213 T122 K91271 X20CRMOV11-10 38X5 High Temperature Boiler Tubes



Product Description:

Seamless Steel Tubes ASTM A 213 T122 K91271 X20CRMOV11-10 38X5 High Temperature Boiler Tubes

X20CrMoV11-10 is a German Steel  high temperature structural steel, tensile strength 690-830 Mpa
Yield strength is min 490Mpa Elongation rate is min 16.8% Impact energy is 41J Brinell hardness 205-250HB



TORICH manufacturing and Supply Capability for Size:

OD 0.5-15mm, WT4.0-80 mm

Tolerance: Outer Diameter: +/- 0.05mm

Thickness: +/- 0.05mm OR as Customer Request with mutual agreement.

Length max 12000mm

Cutting Length available, to specified length by customer’s request.

Max length 5.8 for 20ft container

Max length 11.8m for 40ft container

Steel Grade available:

SAE1010, SAE1020, SAE1045, SAE1026, SAE4130, SAE4140 T12 T22 T91 T5 etc





Heavy Wall Steel Tube Chemical composition min :

C Mn P S Si Ni Cr Mo V B Nb Al
0.17-0.23 0.7 0.02 0.01 0.50 0.50 10.0-11.5 0.25-0.60 0.15-0.30 0.0005-0.005 0.04-0.10 0.02
Cu Ti Zr
0.30-1.70 0.01 0.01



ASTM A 213 T122 K91271 X20CRMOV11-10   are usually used in the following application:

High temperature boiler or exchanger

1: Heavy machinery spare part

2: For Screw Air Compressor

3: For machinery

4: Automobile spare parts





Main Features for TORICH ASTM A 213 T122 K91271 X20CRMOV11-10 e:

High precision for both OD and ID

Good Concentricity,

Good Roundness for easy machining,

Good average Wall thickness for successful turning,

Excellent brightness,

No oxidization scale,

High cleanness inner surface,



Who Torich is?

Our factory was established since 1997, technicians are of great engineering experience in steel pipe industry for more than 20 years



How can Torich service customers?

100% of our steel tubes are dimensionally checked

100% of our steel tubes are visually checked to assure they have a perfect surface condition and no surface defects.

100% eddy current test and ultrosonic test to eliminate longitudinal and transversal defects.
