Astm A513 Automotive 1010 Steel Tube BKS Heatment
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO9001
Trading Properties
Minimum Order Quantity:
2Ton
Payment Terms:
L/C,D/A,D/P,T/T
Supply Ability:
5000Ton per years
Product Summary
Astm A513 1010 Automotive Steel Tube 1. Scope 1.1 This specifification covers electric-resistance-welded carbon and alloy steel tubing for use as mechanical tubing. 1.2 This specifification covers mechanical tubing made from hot- or cold-rolled steel. 1.3 This specifification covers round, square, ...
Product Details
Highlight:
precision a513 tubing
,astm a513 1010 steel tube
,precision 1010 steel tube
Heatment:
BKS, NBK,Stress Relieved Annealing
Technical:
Drawn Over Mandral
Material:
1020,1010
Brand:
TORICH
Product Description
Astm A513 1010 Automotive Steel Tube
1. Scope
1.1 This specifification covers electric-resistance-welded carbon and alloy
steel tubing for use as mechanical tubing.
1.2 This specifification covers mechanical tubing made from hot- or cold-rolled steel.
1.3 This specifification covers round, square, rectangular, and special shape tubing
2. Materials and Manufacture
2.1 The steel may be made by any process.
2.2 If a specifific type of melting is required by the purchaser,it shall be as stated
on the purchase order.
2.3 The primary melting may incorporate separate degassing or refifining,
and may be followed by secondary melting,such as electroslag or vacuum-arc
remelting. If secondary melting is employed, the heat shall be defifined
as all of the ingots remelted from a single primary heat.
Chemical components:
| Grade | Carbon | Manganese | Phosphorus max | Sulfur max |
| 1010 | 0.05-0.15 | 0.3-0.6 | 0.035 | 0.035 |
| 1015 | 0.1-0.2 | 0.3-0.6 | 0.035 | 0.035 |
| X1015 | 0.1-0.2 | 0.6-0.9 | 0.035 | 0.035 |
| 1020 | 0.15-0.25 | 0.3-0.6 | 0.035 | 0.035 |
| X1020 | 0.15-0.25 | 0.7-1 |
Mechanicl Properties:
| Grade | Tensile strength min | Yield strength min | Elongation min | Hardness |
| 1010 | 415 | 345 | 5 | 73 |
| 1015 | 450 | 380 | 5 | 77 |
| 1020 | 480 | 415 | 5 | 80 |
