Tp314n Astm A213 Api Seamless Steel Tube For Heat Exchanger
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO9001
Trading Properties
Minimum Order Quantity:
2Ton
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
50000Ton per year
Product Summary
ASTM A213 Seamless steel Tube for heat exchanger Product details: This specifification2 covers seamless ferritic and austenitic steel boiler, superheater, and heat-exchanger tubes, designated Grades T5, TP304, etc. The tubing sizes and thicknesses usually furnished tothis specifification are 1⁄8 in. ...
Product Details
Highlight:
astm a213 seamless steel tube
,tp314n seamless steel tube
,api seamless steel tube
Place Of Orig:
Zhe Jiang,China
Steel Grade:
TP314N
Type:
Seamless
Section Shape:
Round
Standard:
ASTM
Certification:
API
OD:
0.4-127mm
WT:
3.2mm
Product Description
ASTM A213 Seamless steel Tube for heat exchanger
Product details:
This specifification2 covers seamless ferritic and austenitic steel boiler, superheater,
and heat-exchanger tubes, designated Grades T5, TP304, etc.
The tubing sizes and thicknesses usually furnished tothis specifification are 1⁄8 in. [3.2 mm]
in inside diameter to 5 in.[127 mm] in outside diameter and 0.015 to 0.500 in. [0.4 to12.7 mm],
inclusive, in minimum wall thickness or, if specifified in the order, average wall thickness. Tubing
having other diameters may be furnished, provided such tubes comply with all other requirements
of this specifification.
Materials and Manufacture
Manufacture and Condition—Tubes shall be made bythe seamless process and shall be either
hot fifinished or cold fifinished, as specifified. Grade TP347HFG shall be cold fifinished.
chemical composition %
| Grade | C | Si | Mn | Cr | Ni | Mo | S | P |
|---|---|---|---|---|---|---|---|---|
| TP304 | 0,08 | 1,0 | 2 | 18 – 20 | 8 – 11 | – | 0,03 | 0,045 |
| TP304L | 0,035 | 1,0 | 2 | 18 – 20 | 8 – 12 | – | 0,03 | 0,045 |
| TP316 | 0,08 | 1,0 | 2 | 16 – 18 | 11 – 14 | 2 – 3 | 0,03 | 0,045 |
| TP316L | 0,035 | 1,0 | 2 | 16 – 18 | 10 – 14 | 2 – 3 | 0,03 | 0,045 |
| TP321 | 0,08 | 1,0 | 2 | 17 – 19 | 9 – 12 | – | 0,03 | 0,045 |
| Grade | Tensile Strength(Mpa) | Yield Point(Mpa) | Elongation(%) | Hardness(HRB) | Solution Temperature |
|---|---|---|---|---|---|
| TP304 | 515 | 205 | 35 | 90 | 1040 |
| TP304L | 485 | 170 | 35 | 90 | 1040 |
| TP316 | 515 | 205 | 35 | 90 | 1040 |
| TP316L | 485 | 170 | 35 | 90 | 1040 |
| TP321 | 515 | 205 | 35 | 90 | 1040 |
