ASTM A210 Grade A 1 0.9mm Seamless Steel Tube For Boiler
Basic Properties
Place of Origin:
China
Brand Name:
Torich
Certification:
ISO9001
Trading Properties
Minimum Order Quantity:
5 Ton
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
50000 Ton Per Years
Product Summary
ASTM A210 Grade A-1 Seamless Steel Tube for Boiler Tubing Product Details Standard:ASTM A210 Material :Grade A-1 And Grade C OD :12.7-127mm ID :0.9-12.7mm Technique: Cold-drawn Surface Condition:Pickling Or Shot Blasting Application:For Boilers,Superheaters,Steam linepipes of boilers Chemical ...
Product Details
Highlight:
0.9mm Seamless Steel Tube
,A210 Grade A 1 Seamless Steel Tube
,ASTM A210 Seamless Boiler Tubes
Place Of Origin:
NingBo China
Alloy Or Not:
Non-Alloy
Outer Diameter:
12.7-127mm
Standard:
ASTM A210
Surface Treatment:
Galvanized
Thickness:
0.9-12.7mm
Oiled Or Non-Oiled:
Oiled
MOQ:
5 Tons Hot Dipping Galvanized Stee Pipe/Tube
Product Description
ASTM A210 Grade A-1 Seamless Steel Tube for Boiler Tubing
Product Details
Standard:ASTM A210
Material :Grade A-1 And Grade C
OD :12.7-127mm
ID :0.9-12.7mm
Technique: Cold-drawn
Surface Condition:Pickling Or Shot Blasting
Application:For Boilers,Superheaters,Steam linepipes of boilers
Chemical Composition:
| Steel Grade and Chemical Compositions: | |||||
| Grade | C | Mn | P | S | Si |
| A-1 | ≤0.27 | ≤0.93 | ≤0.035 | ≤0.035 | ≥0.10 |
| C | ≤0.35 | 0.29-1.06 | ≤0.035 | ≤0.035 | ≥0.10 |
Mechanical proporties:
| Grade | Tensil Strength Mpa(ksi) | Yield Point Mpa(ksi) | Elongation |
| A-1 | ≥255(37) | ≥415(60) | ≥30%
|
| C | ≥275(40) | ≥485(70) | ≥30% |
