High Precision Seamless Steel Pipe Honed Tubes E355+C H8 EN-10305/1 OD 380mm
Basic Properties
Place of Origin:
Zhejinag,China
Brand Name:
TORICH
Certification:
ISO9001, ISO14001 ,TS14969
Model Number:
EN10305-1
Trading Properties
Minimum Order Quantity:
2 tons
Price:
888USD/TON
Payment Terms:
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:
50000 tons per year
Product Summary
High Precision Seamless Steel Pipe Honed Tubes E355+C H8 EN-10305/1 OD 380mm TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience. Our main products are seamless precision pipe,carbon steel seamless precision pipe,alloy steel seamless ...
Product Details
Highlight:
e355 precision steel tube
,en10305-1 precision steel tube
,od 380mm precision steel tube
Product Name:
High Precision Seamless Steel Pipe Honed Tubes E355+C
Keyword:
High Precision Seamless Steel Pipe
Application:
For Gas Cylinder Applications, Oil Cylinders/Telescopic Cylinders
Type:
CDS
Material:
E235, E355,E215 ST52,etc
Shape:
Round
Length:
Max 12000mm
OD:
6-380mm
WT:
1-35mm
Brand:
TORICH
Product Description
High Precision Seamless Steel Pipe Honed Tubes E355+C H8 EN-10305/1 OD 380mm
TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience.
Our main products are seamless precision pipe,carbon steel seamless precision pipe,alloy steel seamless precision pipe, stainless steel seamless precision pipe.The material we usually use for producing High Precision Seamless Steel Pipe is10#,20#,1010,1020,1026,ST37,ST44,E235,E215,E355
Standard: EN10305-1 Seamless Cold Drawn/Rolling Steel Tubes
Steel Tubes for precision applications.
Applications: for Gas Cylinder Applications, Oil Cylinders/Telescopic Cylinders
Size Range: O.D.:6-380mm W.T.:1-35mm L:max12000mm
Steel Grade: E235, E355,E215 etc
Note: Special steel grade is also available, according to customer request.
aRm: tensile strength; ReH: upper yield strength; A: elongation after fracture
b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm
Steel Tubes for precision applications.
Applications: for Gas Cylinder Applications, Oil Cylinders/Telescopic Cylinders
Size Range: O.D.:6-380mm W.T.:1-35mm L:max12000mm
Steel Grade: E235, E355,E215 etc
Note: Special steel grade is also available, according to customer request.
aRm: tensile strength; ReH: upper yield strength; A: elongation after fracture
b 1Mpa=1N/mm2
c Depending on the degree of cold work in the finishing pass the yield strength may nearly be as high as the tensile strength.
For calculation purposes the following relations are recommended:
for delivery condition +C: ReH ≥0.8 Rm
for delivery condition +LC: ReH ≥0.7 Rm
| Mechanical properties at room temperature | |||||||||||||
| Steel Grade | Minimum values for the delivery condition | ||||||||||||
| Steel Name | Steel Nubmer | (+Cc) | (+LCc) | (+SR) | (+Ad) | (+N) NBK | |||||||
| Rm Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | Rm Mpa | A % | Rm Mpa | ReH Mpa | A % | ||
| E215 | 1.0212 | 430 | 8 | 380 | 12 | 380 | 280 | 16 | 280 | 30 | 290-430 | 215 | 30 |
| E235 | 1.0308 | 480 | 6 | 420 | 10 | 420 | 350 | 16 | 315 | 25 | 340-480 | 235 | 25 |
| E355 | 1.0580 | 640 | 4 | 580 | 7 | 580 | 450 | 10 | 450 | 22 | 490-630 | 355 | 22 |
