ASTM Bright Annealing Stainless Steel Capillary Tube
Product Details
Bright Annealing Stainless Steel Capillary Tube
,ASTM Stainless Steel Capillary Tube
,Stainless Steel Bright Annealing Tube
TORICH Stainless Steel Small Medical Injection Moulding Machine Medical Tubes
| Commodity name |
Small diameter bright annealing seamless stainless steel capillary tube
|
| Process method | cold rolled/cold drawn |
| Stainless steel grades | TP304/304L, TP310/S,TP316/316L, TP317L, TP321, TP347/H S31803/2205, 904L |
| Standard | ASTM A213, A312, A511, A270, A269, A789, A790, DIN17456, DIN17458, JIS G3463 |
| Size | 0.8x0.1...... |
| Testing | Chemical Analysis. Air Under water Testing Ultrasonic Testing Eddy Current Testing |
| tube surface | Bright annealing |
| Packing | bundle, plywood case, both end with caps,seaworthy packing. |
| Application | 1. General service 2. Curatorial Industry 3. Food Industry 4. Ornamental 5. Aerospace Industry 6. Petrochemical 7. Fluid transport 8. Nuclear Industry 9. Boiler heat- exchanger 10. Oil and gas service |
304 / 304 L:
The most common 300 stainless series alloy, good corrosion resistance, cold working characteristics and
relative cost effectiveness make this our most popular alloy. The "L" grade version has a lower carbon
content for reduced carbide precipitation during secondary welding operations.
17-7:
The addition of aluminum in this alloy provides improved tube strength and hardness while maintaining
good corrosion resistance. Can be heat treated to a higher tensile strength than can be achieved by cold work alone.
302:
Very similar corrosion resistance to stainless 304, but higher strength due to carbon content.
Typically not available in tubing, wire/solid only.
321:
Increased strength and corrosion resistance, especially at higher temperatures, are characteristics of this
alloy due to the addition of titanium to the base metal.
316 / 316 L / 316 LVM:
The addition of molybdenum to the base metal improves corrosion resistance for use in medical / food
service and other demanding tubing applications. "L" grade is a low carbon version for reduced carbide
precipitation during secondary welding operations. 316 LVM is melted in a vacuum to reduce impurities and and
create a uniform chemistry.
303:
An ideal stainless steel alloy for machining parts due to the addition of elements which reduce tool wear / expense.
Available for machined parts only, not offered as tubing.
347:
Characteristics are similar to 321, but the addition of several alloys allows tubing to withstand high temperatures
for longer periods.Aluminum 3000 & 6000 series: Lightweight, cost effective and easy to form, Aluminum is popular
for a variety of applications including aerospace and industrial.
Brass 260:
Composed of 70% Copper and the balance Zinc, this very ductile metal can be used in corrosive environments for
a wide variation of applications from appliance parts and ammunition cartridge cases to ornamental hardware.
-
