Galvalume Steel Coil AZ60 Zinc Aluminized Aluzinc Steel Coil

Place of Origin: Zhejiang China
Brand Name: TORICH
Certification: ISO 9001
Model Number: AZ60
Product Details
Place of Origin:
Zhejiang China
Brand Name:
TORICH
Certification:
ISO 9001
Model Number:
AZ60
Minimum Order Quantity:
1 Ton
Price:
USD 1000-2000 Per Ton
Standard Packaging:
In bundles
Delivery Time:
4-6 Weeks
Payment Terms:
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability:
500 Tons Per Month
Specifications
Micro machining or not:
Micro Machining
Material capabilities:
Aluminum,Stainless Steel,Steel Alloys,Brass,Bronze
Type:
Drilling,Turning
Cnc machining or not:
CNC Machining
Application:
Automobile,Industrial Equipment,Medical,Ecomomical,Sewing Machine
Process:
Assembly,forming
Service:
OEM ODM,ODM Or As Client's Requirement
Product name:
High Quality CNC Lathe Machined Precision OEM Other Auto Parts
Tolerance:
0.01-0.05mm,+/-0.005,+/-0.03mm
Color:
Silver/gold/red/black
Packing:
Poly Bag + Inner Box + Carton
Finish:
E-coat Or Customized,zinc Plating
Highlight:

Galvalume Aluzinc Steel Coil

,

Aluminized Aluzinc Steel Coil

,

AZ60 Zinc Aluzinc Steel Sheet

Product Description

Galvalume Steel Coil AZ60 / Zinc Sheet Steel Aluminized / Aluzinc Steel Coil



ASTM A463 T1 Aluminized Steel is a new type product which is widely used recent years.

It contains 90%aluminium and 10% silicon.

Also, it has good heat resistance, heat reflection and corrosion resistance, and its mechanical

and physical properties are better thancold-rolled steel sheet. Because of its superior performance,

aluminized steel sheet has been widely used in our daily necessities.


For example, automobile mufflers, household appliances, etc. Also included the LNG and gas & oil insulation
terminal projects in Mid east and southeast Asia.



GRADE

THICKNESS

(MM)

WIDTH

(MM)

 YIELD STRENGTH (MPA) TENSILE STRENGTH (MPA)

ELONGATION

(%)

 SURFACE
DC51D+AS 0.5≤t≤2.5 900-1550 - 270-500 >=22 FB-FC
2.5<t≤2.8 900-1410 - 270-500 >=22 FB-FC
2.8<t≤3.0 900-1360 - 270-500 >=22 FB-FC
DC52D+AS 0.5≤t≤2.5 900-1550 140-300 270-420 >=26 FB-FC
2.5<t≤2.8 900-1410 140-300 270-420 >=26 FB-FC
2.8<t≤3.0 900-1360 140-300 270-420 >=26 FB-FC
DX53D+AS 0.5≤t≤2.5 900-1550 140-185 270-330 >=36 FB-FC
2.5<t≤2.8 900-1410 140-185 270-330 >=36 FB-FC
2.8<t≤3.0 900-1360 140-185 270-330 >=36 FB-FC
DX54D+AS 0.6≤t≤2.5 900-1550 120-180 260-330 >=40 FB-FC
2.5<t≤2.8 900-1410 120-180 260-330 >=40 FB-FC
2.8<t≤3.0 900-1360 120-180 260-330 >=40 FB-FC
DX56D+AS 0.8≤t≤2.5 900-1600 120-175 270-310 >=41 FB-FC
2.5<t≤2.8 900-1410 120-175 270-310 >=41 FB-FC
2.8<t≤3.0 900-1360 120-175 270-310 >=41 FB-FC



One of the main purposes of aluminium-silicon coated steel is to replace galvanized products, so aluminium silicon coated products
have the same mechanical properties, dimensionalaccuracy and plate shape control with galvanized products

Because the density of aluminium-silicon is lower than that of zinc, the coating weight canbe less by using aluminium-silicon
coated products instead of glavanized products Aluminium-silicon coated products have excellent corrosion resistance, several or even
a dozen times than that of galvanized products.

Aluminium-silicon products have good high temperature resistance, there almost isn't any change even during long-term use below 550
℃.
The steel plate with aluminium-silicon coating will maintain the bright appearance.
Aluminium-silicon has excellent heat reflectivity, with a light reflectance of about 80% when the temperature below 500 ℃.
The friction coefficient of aluminium-silicon coated products is lower, and low friction
coefficient is favorable for drawing and forming.
