Oiled API 5CT L80 N80 Carbon Steel Drill Steel Pipe Seamless
Product Details
Seamless Drill Steel Pipe
,Cold Drawing Drill Steel Pipe
TORICH API 5CT L80 N80 Seamless Carbon Steel Oil Casing Fluid Pipe
API 5CT L80 Seamless Carbon Steel Oil Casing Pipe
Grade: H40, J55,K55, N80, L80, C90,T95, P110, Q125, V150
Function: Steel pipes used to support oil and gas well walls.
Application: Petroleum casing is a large-diameter pipe that serves to fix oil and natural gas well walls or boreholes. The casing is inserted into the borehole and fixed with cement to help the borehole separate the rock formations and prevent the borehole from collapsing, while ensuring the circulation of drilling mud to facilitate drilling and exploitation.
Length: R-1:4.88~7.62m,R-2:7.62~10.36m,R-3:10.36m to more.
| Grade | C≤ | Si≤ | Mn≤ | P≤ | S≤ | Cr≤ | Ni≤ | Cu≤ | Als≤ |
| API 5CT L80 | 0.15-0.22 | 1.00 | 0.25-1.00 | 0.020 | 0.010 | 12.0-14.0 | 0.20 | 0.20 | 0.020 |
Mechanical Proporties:
| Steel Grade | Yield Strength (Mpa) | Tensile Strength (Mpa) |
| API 5CT L80 | 552-655 | ≥655 |
Dimension Tolerance:
| Types of steel tubes | Outer Diameter | Wall Thickness | |
| Cold-rolled tubes | Tube sizes(mm) | Tolerances(mm) | Tolerances(mm) |
| <114.3 | ±0.79 | -12.5% | |
Show:
FAQ
Q: Are you trading company or manufacturer ?
A: A professional steel pipes materials inventor, manufacturer and solution provider
Q: How long is your delivery time?
A: Generally it is 7-14 days if the goods are in stock. or it is 30-60 days if the goods are not in stock, and it is according to quantity.
Q: Do you provide samples ? is it free or extra ?
A: Yes, we could offer the sample for free charge but you need to pay the cost of freight.
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance , balance before shippment.
If you have another question, pls feel free to contact us
QUALITY CONTROL
1~ Incoming Raw Material Inspection
2~ Raw Material Segregation to avoid steel grade mix-up
3~ Heating and Hammering End for Cold Drawing
4~ Cold Drawing and Cold Rolling, on line inspection
5~ Heat Treatment, +A, +SRA, +LC, +N, Q+T
6~ Straightening-Cutting to specified length-Finished Measuring Inspection
7~ Machanical Testing in own labs with Tensile Strength, Yield Strength, Elongation, Hardness, Impact, Mictrostruture etc
8~ Packing and Stocking.
