Seamless Precision Steel Tube CK45 DIN2391 Cold Rolled Tube
Basic Properties
Place of Origin:
Zhejiang,CN
Brand Name:
TORICH
Certification:
ISO9001 TS16949
Model Number:
DIN 2391
Trading Properties
Minimum Order Quantity:
500kg
Price:
888 USD per ton
Payment Terms:
T/T, L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability:
5000 tons per month
Product Summary
Seamless Precision Steel Tube CK45 DIN2391 Cold Rolled Tube TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience. Our main products are seamless precision pipe,carbon steel seamless precision pipe,alloy steel seamless precision pipe, ...
Product Details
Highlight:
Seamless Precision Steel Tube
,Cold Rolled Precision Steel Tube
,CK45 Precision Steel Tube
Product Name:
Seamless Precision Steel Tube CK45 DIN2391 Cold Rolled Tube
Keyword:
Seamless Precision Steel Tube
Application:
Hydraulic System,Automobile
Standard:
DIN 2391
Technique:
NBK
Surface Treatment:
Galvanized, Customerized, Copper Coated, Null, Polished
Product Description
Seamless Precision Steel Tube CK45 DIN2391 Cold Rolled Tube
TORICH is a professional steel tubes supplier from China with over 23 years manufacturing and exporting experience.
Our main products are seamless precision pipe,carbon steel seamless precision pipe,alloy steel seamless precision pipe, stainless steel seamless precision pipe.The material we usually use for producing Seamless Precision Steel Tube CK45 DIN2391 Cold Rolled Tube is10#,20#,1010,1020,1026,ST37,ST44,E235,E215,E355
Chemical Composition
| Steel grade | C max. | Si max. | Mn max. | P max. | S max. | Altot min. | |
| Name | Number | ||||||
| E215 | 1.0212 | 0.10 | 0.05 | 0.7 | 0.025 | 0.015 | 0.025 |
| E235 | 1.0308 | 0.17 | 0.35 | 1.2 | 0.025 | 0.015 | -- |
| E355 | 1.0580 | 0.22 | 0.55 | 1.6 | 0.025 | 0.015 | -- |
Tolerance
| Outer Diameter | Allowable tolerance | special tolerance | ||
| GB/T3639 | DIN2391 | OD | WT | |
| 4mm-20mm | ±0.10mm | ±0.08mm | ±0.05mm | ±0.05mm |
| 20mm-30mm | ±0.10mm | ±0.08mm | ±0.08mm | ±0.08mm |
| 31mm-40mm | ±0.15mm | ±0.15mm | ±0.10mm | ±0.08mm |
| 41mm-60mm | ±0.20mm | ±0.20mm | ±0.15mm | ±0.15mm |
| 61mm-80mm | ±0.30mm | ±0.30mm | ±0.20mm | ±0.20mm |
| 81mm-120mm | ±0.45mm | ±0.45mm | ±0.30mm | ±0.30mm |
Mechanical Properties
| Steel grade | Yield strengtha | Tensile strength | Elongation | |
| Name | Number | ReH | Rm | A |
| min. | min. | min. | ||
| MPa | MPa | % | ||
| E215 | 1.0212 | 215 | 290 to 430 | 30 |
| E235 | 1.0308 | 235 | 340 to 480 | 25 |
| E355 | 1.0580 | 355 | 490 to 630 | 22 |
Delivery Condition
| Designation | Symbol | Description |
| Cold finished (hard) | BK(+C) | Tubes do not undergo heat treatment following the final cold forming and, thus, have a rather high resistance to deformation |
| Cold finished (Soft) | BKW (+LC) | The final heat treatment is followed by cold drawing involving limited deformation. Appropriate further processing allows a certain degree of cold forming (e.g. bending, expanding) |
| Cold finished and stress-relieved | BKS(+SR) | Heat treatment is applied following the last cold forming process. Subject to appropriate processing conditions, the increase in the residual stresses involved enables both forming and machining to a certain degree. |
| Annealed | GBK(+A) | The last Cold forming process is followed by annealing in a controlled atmosphere. |
| Normalized | NBK(+N) | The last cold forming process is followed by annealing above the upper transformation point in a controlled atmosphere. |
